(888) 312-8812 Login SignupRAYBESTOS 681012R Raybestos R-Line Brake Rotor
$8349
Limited availability at this price!
In Stock
Get it by Thursday, Jul 9
RAYBESTOS 681012R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2020-2013 Ford Fusion Rear, 2016-2013 Lincoln MKZ Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 681012R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.5 IN |
| Center Hole Diameter | 63.5 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.374 IN |
| Discard Thickness | 9.5 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 8.406 IN |
| Inside Diameter | 213.5 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.252 IN |
| Mounting Bolt Hole Circle Diameter | 108 MM |
| Mounting Bolt Hole Diameter | 0.543 IN |
| Mounting Bolt Hole Diameter | 13.8 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.433 IN |
| Nominal Thickness | 11 MM |
| Outside Diameter | 11.882 IN |
| Outside Diameter | 301.8 MM |
| Overall Height | 2.004 IN |
| Overall Height | 50.9 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213080117 |
RAYBESTOS 681012R Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH479084, YH479084C, YH479084P |
| AUTOPARTSOURCE | 492747 |
| AUTOXTRA | AX901166 |
| AUTOZONE | 75013, 75013DG, 75013DL |
| Autoxtra | AX901166P |
| BENDIX | PRT6205 |
| BRAKEBEST | 681012, 681012R, 681012RGS |
| Bosch | 20011624 |
| CENTRIC | 120.61103, 121.61103, 126.61103CSL, 126.61103CSR, 126.61103SL, 126.61103SR, 127.61103L, 127.61103R, 128.61103L, 128.61103R, 320.61103, 321.61103 |
| Centric Parts | 120.61103, 121.61103, 126.61103CSL, 126.61103CSR, 126.61103SL, 126.61103SR, 127.61103L, 127.61103R, 128.61103L, 128.61103R, 320.61103, 321.61103 |
| DURA CORP | BR901166, BR90116602 |
| DuraGo | BR901166, BR90116602 |
| Dynamic Friction Company | 600-54068 |
| FORD | DG9Z2C026A, DG9Z2C026C, KS7Z2C026B |
| MAGMA PRODUCTS | PMR203089 |
| Motorcraft | BRRF305, NBRR24 |
| NEWTEK AUTOMOTIVE | 54194, R1166 |
| Newtek Automotive USA | 54194, R1166 |
| POWERSTOP | AR85156EVC |
| PROMAX | 14-54194 |
| Qualis | 42287 |
| TopNotch | TN681012GEO |
| UAP | 2901168 |
| WAGNER BRAKE | BD180379, BD180597 |
| WINHERE | 6612052 |
| WORLDPAC | 1407-479084, 1427-613612 |
| WORLDPARTS | WS1-154194 |
| Wagner Brake | BD180597E |
RAYBESTOS 681012R Fits Vehicles
- Lincoln MKZ (2013-2016)
- Ford Fusion (2013-2020)
RAYBESTOS 681012R Customer Reviews
No reviews yet
Be the first to review this product!
RAYBESTOS 681012R Questions & Answers
No questions yet
Be the first to ask a question about this product!
