(888) 312-8812 Login SignupRAYBESTOS 980934 Raybestos Specialty - Street Performance Coated Brake Rotor
$111.13
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 980934 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Coated Brake Rotor
Application Summary
2011-2007 Mercedes-Benz S550 Rear, 2012-2007 Mercedes-Benz SL550 Rear, 2008-2007 Mercedes-Benz CL550 Rear, 2012-2010 Mercedes-Benz S400 Rear
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 980934 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.638 IN |
| Center Hole Diameter | 67 MM |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Discard Thickness | 0.394 IN |
| Discard Thickness | 10 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 8.23 IN |
| Inside Diameter | 209.05 MM |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Mounting Bolt Hole Circle Diameter | 112 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.472 IN |
| Nominal Thickness | 12 MM |
| Outside Diameter | 11.81 IN |
| Outside Diameter | 299.95 MM |
| Overall Height | 2.3 IN |
| Overall Height | 58.4 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | DE |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213020632 |
RAYBESTOS 980934 Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | N1000234010ZIC |
| ATE BRAKE PRODUCTS | 424212, 424226, SP24212 |
| AUTOZONE | 76603, 76603DG |
| Advance Auto Parts | YH287476 |
| BENDIX | BPR6272 |
| BOSCH | 36010994 |
| BRAKEBEST | 36010994, 980934, 980934RGS |
| Brembo | 08.A734.11 |
| CENTRIC | 120.35098, 121.35098, 125.35098, 126.35098CSL, 126.35098CSR, 126.35098SL, 126.35098SR, 127.35098CL, 127.35098CR, 127.35098L, 127.35098R, 128.35098CL, 128.35098CR, 128.35098L, 128.35098R, 320.35098C, 320.35098H |
| Centric Parts | 120.35098, 121.35098, 125.35098, 126.35098CSL, 126.35098CSR, 126.35098SL, 126.35098SR, 127.35098CL, 127.35098CR, 127.35098L, 127.35098R, 128.35098CL, 128.35098CR, 128.35098L, 128.35098R, 320.35098C, 320.35098H |
| DURA CORP | BR34492 |
| DuraGo | BR901222, BR34492 |
| MAGMA PRODUCTS | PSR383065 |
| MERCEDES-BENZ | 2214230712 |
| N/A | 120.35096 |
| PAGID | 355113992, 355115412 |
| PAGID Racing | 355113992, 355115412 |
| POWERSTOP | EBR1049EVC |
| Qualis | 45489 |
| UAP | R35098 |
| VAICO | V3040017 |
| WAGNER BRAKE | BD180149 |
| WORLDPAC | 1427-530041 |
| Winhere | 6620466 |
RAYBESTOS 980934 Fits Vehicles
- Mercedes-Benz S400 (2010-2013)
- Mercedes-Benz CL550 (2007-2008)
- Mercedes-Benz SL550 (2007-2012)
- Mercedes-Benz S550 (2007-2011)
