(888) 312-8812 Login SignupHELLA 355016861 Disc Brake Pad Set
$3949
Limited Availability
Due to limited availability, we will confirm your order and notify you within 1 business day.
HELLA 355016861 Part Description
Manufacturer
Product Description
Disc Brake Pad Set
Features & Benefits
- Ensures optimal braking performance with low-metallic formulation, enhancing efficiency and reducing brake dust.
- Offers reliable performance in high temperatures with excellent fade stability and effective heat dissipation.
- Provides universal compatibility, ensuring seamless integration with most European vehicles.
- Maintains consistent pedal feel with low compressibility, enhancing driver control and comfort.
- Meets ECE-R90 standards, ensuring compliance with European safety regulations and optimal braking performance.
Disc Brake Pad Set
Brake Pad
HELLA 355016861 Specifications
Product Attributes
| Outer Pad Friction Material Thickness | 0.5 IN |
| Wear Indicator Attached | Yes |
| Pad Wear Sensor Included | Yes |
| Slotted | No |
| Friction Material Composition | Low-Metallic |
| Mounting Hardware Included | Yes |
| Grade Type | Standard Replacement |
| Pad Shims Included | Yes |
| Brake Lubricant Included | No |
| Pad Quantity | 4 |
| Inner Pad Friction Material Thickness | 0.5 IN |
| Abutment Clips Included | Yes |
| Pad Wear Sensor Type | Mechanical |
| Chamfered Edges | Yes |
| Prepared For Pad Wear Sensor | Yes |
| ECE-R90 Certified | Yes |
| Adhesive Backed Pad Shim | Yes |
| Outer Pad Height | 2.3 IN |
| Inner Pad Height | 2.3 in |
| Outer Pad Width | 4.3 IN |
| Inner Pad Width | 4.3 in |
| Assy/Disassy by Qualified Personnel Required! | . |
| Brake System | Sumitomo |
| California Proposition 65 Required | No |
| Height [mm] | 57.2 |
| Number Of Wear Indicators [per Axle] | 2 |
| Supplementary Article/Supplementary Info | with Accessories |
| Technical Information Number | T3073 |
| Thickness [mm] | 14 |
| Wear Warning Contact | with Acoustic Wear Warning |
| Weight [kg] | 1.18 |
| Width [mm] | 110.7 |
| WVA Number | 23354 |
| Outer Pad Friction Material Thickness | 13.60 MM |
| Inner Pad Friction Material Thickness | 13.60 MM |
| Outer Pad Height | 57.20 MM |
| Inner Pad Height | 57.20 MM |
| Outer Pad Width | 110.30 MM |
| Inner Pad Width | 110.30 MM |
Additional Information
| Country of Origin (Primary) | IN |
| Harmonized Tariff Code (HTS) | 8708305040 |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| UPC | 04082300361179 |
HELLA 355016861 Cross References
| Brand | Part Number |
|---|---|
| AISIN | BPMZ2005, E1N022, SN285P |
| Bendix | 510298, DB1282 |
| Bosch | 0 986 494 080, 0 986 AB1 140, 0 986 AB2 184, 0 986 AB2 454, 0 986 TB2 258, 0986494655, BP990 |
| Brembo | 07B31406, P49020, P49020N |
| Datsun/Nissan | AY040MA014 |
| Delphi | LP1074 |
| Hella Pagid | 8DB355016861, T3073 |
| Magneti Marelli | 363700203073, 363702160757, 600000098260, T3073MM |
| Mazda | 1U163328Z, N0Y33323Z, N0Y33328Z, NAY5-33-8ZA, NAY533232, NAY53323Z, NAY53323ZA, NAY53323ZB, NAY53328Z, NAY53328ZB, NCY03323Z, NCY03328Z, NCY1-33-3Z, NCY13323Z, NCY13323ZA9C, NCY13328Z9C, NCY53323Z, NCY53328Z |
| Mintex | MDB1686 |
| Mitsubishi | NAY53323ZC, NAY53328ZA, NCY13323Z9C |
| N/A | 7513D635, T3073, BP12326, 12326, MDB1686FR, 6131039, BL1628A2, 9010255, 9002100, BBP1583, FDB1011, FSL1011, FCP1011R, FCP1011H, 1310-0890-01, 1311-0635-00, 1311-0635-01, 1311-0890-01, 1000-0635-00, 1000-0890-00, 1551-0635-00, 1551-0890-01, 1551-0635-01, 1115-0635-00, 1115-0635-01, 1115-0890-00, 1115-0890-01, 1310-0635-00, 1310-0635-01, PCP1926, 8224720, M05406, NCY13328Z, 2204720, ISD635, ACT635, AN461K, AN461KE, 223234, SS276S, SS285S, E1N022, SN285P, PN5364, DP21002, DP1002, NCY13323Z9C, NAY53323ZC, NAY53328ZA, 2903, BP906, SP1539, SP1524, FO638981, 302842, 1050587, 0478.02, D635-7513, 811050017, FBP1813, 16497, T8171SP2001, D635, J3603044, 247802, 047802, ADM54252, DBP10741, DBP1074, ADP118202, ADP1182, ADP118201, DBP10742, 233541401, 2335413614, 2335404, 6588, PBP7416, 192949, 605834, 13046058342, DB1282SRT, DB1282ULT, DB1282GCT, PA383AF, PA395AF, PA388AF, TRH0635, GDB3103DT, GDB3103, GDB7078, RCPT13050, PA1327, 05P1043, ZX635, ZD635, WBP23354A, 0252335414, 572385J |
| TRW | GDB3103, GDB7078, RCPT13050 |
| Valeo | 598836, 670836 |
HELLA 355016861 Fits Vehicles
- Mazda Miata (1994-1997, 1999-2005)
