(888) 312-8812 Login SignupMGM BRAKES 3545955 Air Brake Chamber - Combination, 2.87" Welded Yoke, Neoprene Diaphragm, Welded NPC
MSRP: $435.18
$39499
Save $40.19
Limited availability at this price!
In Stock
Get it by Tuesday, Jan 13
MGM BRAKES 3545955 Part Description
Manufacturer
Product Description
Double Diaphragm Brake Chamber
Features & Benefits
- Tamper Resistant
- Long Life Spring
- Center Hole Diaphragm/Shield
- Epoxy Coated Head, NPC, Lower Push-Rod Assembly, Return Spring, Piston/Center Case
- Heavy-Duty Steel NPC
- Polymer Guides
- Heavy-Duty Diaphragm
- Stroke Alert
- Composite Guide
W/WELDED CLEVIS
MGM BRAKES 3545955 Specifications
Product Attributes
| Artic Assembly | Artic Assembly |
| Breather Tube | Breather Tube |
| Chamber Type | Double Diaphragm Brake |
| Diaphragm Diameter | Neoprene IN |
| Heavy Duty | Heavy Duty |
| Mounting Bolt Length | 1.490 IN |
| Mounting Bolt Thread | 5/8-11 |
| Port Size | 3/8-18 NPTF |
| Spring Size | 30 |
| Service Size | 30 |
| Severe Service | Severe Service |
| Stroke | 3.00 IN |
| Welded Mounting Bolts | Welded Mounting Bolts |
| Welded Yoke | Welded Yoke |
| UNIT | Aftermarket |
Additional Information
| Country of Origin (Primary) | US |
| 2 | |
| VMRS Code | 013004000 |
