Name: Peterson Lighting V701C LED Headlight, Round, Par 56, 7", white, Viz Pack
SKU: v701c
Price: 935.96 USD
Availability: InStock

PETERSON LIGHTING part description

701 Great White® LED 7" PAR 56 Round Headlight

Peterson Lighting Great White® LED 7" PAR 56 Round Headlight

The Peterson Lighting Great White® LED 7" PAR 56 round headlight is a cost-effective investment since it offers a longer service life than standard headlights. It is suitable for mounting on any truck, and it is made temperature-, weather-, and vibration-resistant to ensure a safer driving experience.

Features & Benefits

Made with heavy-duty polycarbonate lens that is bonded to a rugged aluminum housing to form a single unit
Designed to replace standard 7" incandescent sealed beam
With superior light output but consumes low power as it draws only 17 to 22 watts
Has standard H4 electrical connection with separate high beam (1650 lumens) and low beam (1100 lumens) functions
Can be used on CANBUS-equipped vehicles, including '07 and newer Jeep Wrangler, but requires a 701-491 anti-flicker harness
Not ECE-compliant but DOT-legal, exceeding FMVSS 108 and CMVSS 108 requirements and meeting applicable SAE standard
Operating range is 9 to 32 volts with form factor that matches a standard 2D1 configuration
Must not be used as a daytime running light (DRL)
IP66 ingress-rated with its patent pending

Product Description

LED HEADLIGHT, ROUND, PAR 56, 7"

Features & Benefits

7" Round PAR 56 Headlight
Drop-in LED replacement for all PAR56 7-inch standard headlights.
Multi-volt design is compatible with both 12V and 24V systems.
DOT-legal; exceeds FMVSS-108 and CMVSS-108 requirements.
Standard H4 3-blade terminals integrated into cast alloy rear housing.
1100 / 1650 lumen output (low / high beam).
Draws only 0.7–1.9 amps.
5400 – 6400k color temperature closely matches natural daylight.
Certified to meet IP66 ingress protection rating.
Heavy-duty polycarbonate lens and cast alloy housing.
Does not function as a daytime running light (DRL).
Requires 701-491 anti-flicker harness for use on CANBUS-equipped vehicles, including '07 and newer Jeep Wrangler.
V701KC-2 Kit includes 2 headlights & two 701-491 anti-flicker harnesses.
For left-hand traffic, see ECE version on Peterson's website.

anti-flicker harness - Viz Pack - 701-491 - std qty

Product Attributes

Average Current Draw	1.66 68
Brightness	1650 LU
Bulb Technology	LED
Bulb/diode Count	2
California Prop65 Required	Y
Color Temperature	5400 - 6400k
Container Type	Viz Pack
Diameter	7 IN
Height	7 in
Length	7 in
Lens Color	clear
Light Color	white
Maximum Amperage Draw	1.992 68
Maximum Voltage	32 Volts
Minimum Voltage	9 Volts
Multi-volt	Y
Regulatory Compliance	DOT
Shape	round
Termination	H4
Voltage	12V / 24V
Width	3.9 in

Additional Information

Warranty Special	See full warranty terms: https://pmlights.com/warranty
Warranty Special UOM	TX
Warranty Time	3
Warranty Time UOM	YR
Country of Origin (Primary)	US
Harmonized Tariff Code (Schedule B)	8512202000
UPC	00044464991177
VMRS Code	034001151

Part Interchanges

Grote 90941-5

PETERSON LIGHTING V701C Cross Reference

We have 2 alternatives for the V701C by PETERSON LIGHTING:

Peterson Lighting® is a family-owned company that produces and distributes vehicle safety lighting systems mirrors, and other related safety products and accessories. It has been in the business for 75 years, and currently, it offers over 2,200 products designed for various applications, including tilt-bed and cargo vehicles and light- and medium-duty trailers. Peterson Lighting believes that full commitment to quality is its responsibility as a market leader. All its components are designed and manufactured only in its ISO 9001/QS-9000-certified facility in Grandview, MO. This facility is handled by knowledgeable and highly skilled specialists, who are as dedicated and passionate as the company when it comes to quality.
