PETERSON LIGHTING part description

882-7/883-7 LumenX® 4" Round LED Combo Stop/Turn/Tail and Back-Up Light

Peterson Lighting LumenX® 4" Round LED Combo S/T/T & Back-Up Light

For enhanced trucking safety, equip your truck with a high-quality Peterson Lighting LumenX® 4” round LED combo S/T/T & back-up light . This product effectively combines all three crucial functions—stop, turn, and tail— into one industry-standard light, and it comes with an auxiliary back-up light function.

Features & Benefits

  • A grommet-mount 7-diode S/T/T light with white diodes behind the red lens and also works as a back-up light when used in pairs
  • With a Cyclops-style design for a more unique look
  • Designed to accept all AMP-compatible connectors for S/T/T and backup light functions
  • With fully illuminated lens because of advanced optics
  • Provides voltage protection and consistent light output over the entire voltage range with its regulated design
  • Product’s operating range is 9 to 16 volts with patent still pending
  • Available as a kit that already includes light, grommet, and AMP-style plug
  • Does not have to be “Top” positioned to meet FMVSS 108 requirements
  • Engineered to meet the needs of any stop tail turn lighting situation

Product Description

LED STOP/TURN/TAIL, & BACK-UP LIGHT, ROUND, GROMMET-MOUNT W/PLUG, KIT 4"

Features & Benefits

  • 7 diodes.
  • Defender harness & lighting system approved.
  • Lumenx® lens and circuitry.
  • Made in USA.
  • Multivolt version available.
  • Voltage Regulated.
  • Cyclops-style design integrates back-up light into stop/turn/tail light.
  • Single bright white diode meets legal back-up light req. used in pairs.
  • Available w/ integral AMP-compatible receptacles or hardwired leads.
  • –7P versions have hardwired PL3 receptacle.
  • Available in 9-16 volt or 9-32 (-MV) operating ranges.
  • Does not require “Top” positioning to meet FMVSS 108 standard.
  • Kits include B880-49 and B417-49 plugs, plus grommet where req.

426-18: grommet (poly pack - std qty 12)

Product Attributes

Bulb Technology LED
Bulb/diode Count 7
California Proposition 65 Required Y
Container Type poly bag
Diameter 4.25 IN
Family LumenX
Height 4.25 in
Integral Reflex N
Length 4.25 in
Lens Color red + clear
Light Color red + white
Marine Use Y
Maximum Voltage 16 Volts
Minimum Voltage 9 Volts
Mounting Type grommet
Multi-volt N
Regulatory Compliance DOT
Shape round
Termination AMP
Termination 2 AMP
Voltage 12 Volts
Width 1.42 in

Additional Information

Country of Origin (Primary) US
Harmonized Tariff Code (Schedule B) 8512204000
UPC 00044464994673
VMRS Code 034002059

Peterson Lighting® is a family-owned company that produces and distributes vehicle safety lighting systems mirrors, and other related safety products and accessories. It has been in the business for 75 years, and currently, it offers over 2,200 products designed for various applications, including tilt-bed and cargo vehicles and light- and medium-duty trailers. Peterson Lighting believes that full commitment to quality is its responsibility as a market leader. All its components are designed and manufactured only in its ISO 9001/QS-9000-certified facility in Grandview, MO. This facility is handled by knowledgeable and highly skilled specialists, who are as dedicated and passionate as the company when it comes to quality.
