(888) 312-8812 Login SignupGATES 2/TR28492PB Green Stripe PowerBand Truck & Bus Series Joined V-Belt
Tap to view 1 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
GATES 2/TR28492PB Part Description
Manufacturer
Product Description
Green Stripe PowerBand Truck & Bus Series Joined V-Belt
Application Summary
1996-1991 Freightliner, FLD, Cummins N14 Diesel, Fan
Features & Benefits
- Molded notches reduce bending stress, especially on small diameter pulleys, while dissipating heat
- High modulus, high strength tensile cord
- Oil and heat-resistant construction throughout
- Meets SAE J636b and SAE J637 specifications
- Meets RMA oil and heat resistant standards and static conductivity requirements
- NOTE: Some sizes available as Gates PowerBand joined V-belts
GATES 2/TR28492PB Specifications
Product Attributes
| Type | Truck & Bus Joined V-Belt |
| Cross Section Designation | VA |
| Angle | 36 |
| Strand Quantity | 2 |
| Top Width | 1.8125 in |
| Top Width Per Strand | .875 IN |
| Outside Circumference | 50.36 in |
| Effective Length | 49.35 in |
| Construction | Notched |
| Notched | Yes |
| Belt Material | EPDM |
| Cord Material | Polyester |
| Top Width | 46 mm |
| Top Width Per Strand | 22 MM |
| Outside Circumference | 1279 mm |
| Effective Length | 1253 mm |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4010323000 |
| Country of Origin (Primary) | US |
| UPC | 00072053284331 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
GATES 2/TR28492PB Cross References
| Brand | Part Number |
|---|---|
| 85410112 | |
| ACDelco | 2T28492 |
| Alliance Truck Parts | GT2/TR28492PB, GT2PB28496, GT2PB28496E |
| Carquest | 2/TR28492PB |
| DAYCO | 28490 |
| GOODYEAR BELTS | 2/28492 |
| International Harvester (IHC) | 488674C91 |
| NAPA | 25-12500-2 |
| NAPA Belts/Hose | 25-28492-2 |
GATES 2/TR28492PB Fits Vehicles
- Peterbilt 352 (1981)
- International CO9670 (1988)
- International F9370 (1985)
- International F5070-WW (1993)
- Freightliner FLB (1994-1996)
- Freightliner FLA086 (1989-1994)
- International F5070-SF (1985-1987)
- International F5070 (1985-1993)
- International 5070 (1985-1993)
- Autocar C / DC (1981-1984)
- Freightliner FLD120 (1988-1996)
- Freightliner FLT086 (1981-1988)
- Freightliner FLC112 (1985-1996)
- Freightliner FLC120 (1981-1988)
- Western Star WSH (1982-1983)
- Mack WS (1984)
- Western Star 6900 (1989-1990)
- Western Star 4900 (1981-1990)
- Kenworth K100 (1981-1985)
- Western Star 4800 (1981-1990)
- Mack RWS (1981-1985)
- Mack RW (1985-1991)
- Mack RWL (1981-1985)
- Mack MH (1984-1990)
- Kenworth C500 (1992)
- Peterbilt 359 (1981-1987)
- Peterbilt 357 (1987)
- Peterbilt 362 (1981-1996)
- Kenworth K100E (1985-1999)
- Mack R (1981-1985)
- Kenworth W900 (1986-1990, 1993-1996)
- International 9700 (1996)
- International 9600 (1994-1996)
- International 9200 SBA (1995-1996)
- International 9400 (1991, 1994)
- International COF9670 (1988)
- International 9300 (1988, 1991, 1994)
- International 9370 (1985)
- Peterbilt 282 (1965-1966, 1971-1980)
- International 9800 SBA (1996-1999)
- International 5000 (1990-1993)
- White/GMC WCM (1988)
- White/GMC WHM (1988)
- White/GMC WCL (1988)
- White/GMC WCA (1988)
- White WHM (1981, 1984-1987)
- White WCM (1981-1988)
- White WIM (1984)
- White WHS (1981-1988)
- Ford CLT9000 (1981-1989)
- White WHL (1981-1988)
- White WCS (1981-1988)
- White WCL (1982-1988)
- White WCA (1988)
- White/GMC WHS (1988)
- White/GMC WHL (1988)
- White/GMC WCS (1988)
- Ford CL9000 (1981-1989)
