(888) 312-8812 Login SignupGATES 2/9490PB Green Stripe PowerBand Heavy-Duty Joined V-Belt
Tap to view 1 more
$56.38
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
GATES 2/9490PB Part Description
Manufacturer
Product Description
Green Stripe PowerBand Heavy-Duty Joined V-Belt
Application Summary
1999-1990 Peterbilt, 379, Caterpillar 3406 Diesel, Alt.
Features & Benefits
- Unique tensile cord design gives belt extra strength, added flexibility and shock-load resistance
- Molded notches reduce bending stress, especially on small diameter pulleys, while dissipating heat
- Even load distribution between strands provides better shock-load absorption
- Eliminates belt turnover or belts jumping off the drive
- Meets or exceeds SAE J636 specifications
- Meets RMA oil and heat resistant standards and static conductivity requirements
GATES 2/9490PB Specifications
Product Attributes
| Type | High Capacity Joined V-Belt |
| Cross Section Designation | HC50 |
| Angle | 36 |
| Strand Quantity | 2 |
| Top Width | 1.125 in |
| Top Width Per Strand | .5 IN |
| Outside Circumference | 50.01 in |
| Effective Length | 49.13 in |
| Construction | Notched |
| Notched | Yes |
| Belt Material | EPDM |
| Cord Material | Polyester |
| Top Width | 28 mm |
| Top Width Per Strand | 13 MM |
| Outside Circumference | 1270 mm |
| Effective Length | 1248 mm |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4010323000 |
| Country of Origin (Primary) | US |
| Stock Status | N |
| UPC | 00072053416701 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
GATES 2/9490PB Cross References
GATES 2/9490PB Fits Vehicles
- Volvo WI (1996-1998)
- Peterbilt 376 (1991-1992)
- Peterbilt 377 (1990-1999)
- Peterbilt 357 (1990-1999)
- Peterbilt 379 (1990-1999)
- Peterbilt 378 (1990-1999)
- Kenworth W900 (1990-1993)
- International 8200 (1990-1994)
- International 8300 (1990-1994)
- Blue Bird SHL All American (1988-1989)
- White/GMC WIA (1990-1993, 1995)
- White/GMC WCA (1990-1993)
