Gates 70760 - Global G1H 1-Wire Braid Hose - High-Temp - SAE 100R1 Type AT
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
GATES part description
Product Description
Global G1H 1-Wire Braid Hose - High-Temp - SAE 100R1 Type AT
Features & Benefits
- For use with GlobalSpiral Couplings [G20 Series], GlobalSpiral Plus Couplings [G22 Series], MegaCrimp Couplings [G25 Series] and Stainless Steel Braid Couplings [G17 Series]
- Provides tighter than standard minimum bend radius and greater flexibility for easier plumbing routing
- Meets Flame Resistance Acceptance Designation MSHA 2G
- Temperature Range: Hydraulic Oil Lines: -40 Deg. F to +275 Deg. F (-40 Deg. C to +135 Deg. C) constant; +300 Deg. F (+149 Deg. C) intermittent (up to 10 percent of operating time)
Product Attributes
| Product Type | Global G1H 1-Wire Braid Hose - High-Temp - SAE 100R1 Type AT |
| Industrial Description | 16G1HXREEL |
| Type | Hydraulic Hose |
| Hose Pressure Description | Medium Pressure |
| Maximum Working Pressure | 1000 PS |
| Burst Pressure | 4000 PS |
| Temperature Rating | -40 Deg. F to +275 Deg. F (-40 Deg. C to +135 Deg. C) |
| Length | 165 FT |
| Dash Size | 16 |
| Inside Diameter | 1 IN |
| Outside Diameter | 1.41 IN |
| Bend Radius | 12 IN |
| Tube Description | Black, Oil-Resistant, Synthetic Rubber |
| Hose Material | Nitrile - Type C |
| Reinforcement Material | One Braid of High-Tensile Steel Wire |
| Cover Material | Synthetic Rubber - CSM - Type M |
| Cover Type | Type M - Flame, Oil & Abrasion Resistant |
| Cover Color | Black |
| Coupling Recommendation | GlobalSpiral, MegaCrimp |
| SAE Standard | 100R1 |
| EN Standard | 854 1SN |
| ISO Standard | 1437 1SN R1 |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4009210000 |
| Country of Origin (Primary) | US |
| UPC | 00770075153351 |
| VMRS Code | 059032029 |
| UNSPSC | 40142020 |
Part Interchanges
