(888) 312-8812 Login SignupDELPHI ES20145 Oxygen Sensor
MSRP: $86.40
$7849
Save $7.91
Limited availability at this price!
In Stock
Get it by Thursday, Jul 30
DELPHI ES20145 Part Description
Manufacturer
Product Description
Oxygen Sensor
Features & Benefits
- Delphi planar technology covers older, conical design sensors
- Smart design consolidates SKUs without using long wires
- Patented protective sensor coating helps prevent contamination
- Validated for all fuel types, including ethanol blends like E85
- OE tested to 150,000 miles, plus 2,000 hours severe thermal testing
- Delphi is a global OE manufacturer for oxygen sensor and all oxygen sensors are built to Delphi's OE standards
DELPHI ES20145 Specifications
Product Attributes
| Package Contents | Oxygen Sensor, Instruction Sheet |
| Position(s) | Front, Front Left, Rear, Rear Left. For the position specific to your vehicle, refer to the Applications. |
| Wiring Harness Length | 13.9 IN |
| Wiring Harness Length | 353.0 MM |
| Sensor Type | Narrow-Band |
| Terminal Type | Blade |
| Universal Or Specific Fit | Specific |
| Band Type | Narrow |
| Wire Quantity | 4 |
| Grade Type | Standard Replacement |
| Connector Shape | Square |
| Terminal Quantity | 4 |
| Connector Gender | Female |
| Terminal Gender | Female |
| Thread Diameter | 0.7 IN |
| Wrench Size | 22mm |
| Thread Size | M18 - 1.5 |
| Overall Length | 15.1 IN |
| Overall Length | 383.0 MM |
| Mounting Type | Threaded |
| Thread Diameter | 18.0 MM |
| Wire Gauge Measurement | 20.0 GU |
| Thread Type Standard | Metric |
| Heated | Yes |
Additional Information
| Harmonized Tariff Code (HTS) | 9027102000 |
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9027100000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| UPC | 00689604146002 |
| VMRS Code | 045021011 |
| UNSPSC | 41111924 |
DELPHI ES20145 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 2131284, 2131285, 2131286, 2131365, 2131368, 2131409, 2131441, 2131490 |
| BorgWarner | OS1794, OS1797, OS1833, OS1835, OS1838, OS199, OS846 |
| Bosch | 13287, 13870, 13888, 13971, 15262, 13289, 13579 |
| DENSO | 234-4721, 234-4041, 234-4427, 234-4629 |
| DENSO Auto Parts | 234-4041, 234-4427, 234-4629, 234-4721 |
| Ford | F62F 9F472-DD, F62Z 9F472-DD, FS2V-18-861B9U, FS7N-18-8619U, FSC6-18-861A9U, KL61-18-861A9U, TA34-18-861B9U |
| Kem | 138-307, 138-610, 138-695 |
| Mazda | FS1G-18-861, FS1G-18-861A, FS2V-18-861A, FS2V-18-861B, FS2V-18-861B9U, FS7N-18-861, FS7N-18-8619U, FSC6-18-861, FSC6-18-861A, FSC6-18-861A9U, FSD7-18-861, FSD7-18-861A, KL61-18-861, KL61-18-861A, KL61-18-861A9U, TA34-18-861, TA34-18-861A, TA34-18-861B, TA34-18-861B9U |
| Motorcraft | DY-784 |
| N/A | 25024629, 2344041, 2344629, 2344721, FS1G18861, FS1G18861A, FS2V18861A, FS2V18861B, FS7N18861, FSC618861, FSC618861A, FSD718861, FSD718861A, KL6118861, KL6118861A, TA3418861, TA3418861A, TA3418861B, 1821385Z10, 138307, 138610, 138695, F62F9F472DD, F62Z9F472DD, FS2V18861B9U, FS7N188619U, FSC618861A9U, KL6118861A9U, TA3418861B9U, DY784, 250-241126 |
| NTK | 22002, 22091, 22098, 22103, 22533, 25185 |
| Oextra | REA1053 |
| SPECTRA PREMIUM | OS5371, OS5156 |
| Standard Motor Products | SG1040, SG1043, SG1079, SG1081, SG1084, SG320, SG321, SG550 |
| Suzuki | 18213-85Z10 |
| VEMO | V32760008, V32760011 |
| Walker Products | 250-24629 |
| Wells | SU2094, SU4577, SU4586, SU4609, SU5247, SU5794, SU5806 |
DELPHI ES20145 Fits Vehicles
- Suzuki Reno (2005)
- Suzuki Forenza (2004-2005)
- Mazda Protege5 (2002-2003)
- Mazda 626 (1996-2000)
- Mazda Protege (2001-2003)
- Mazda Millenia (1995-2002)
- Mazda MX-6 (1997)
- Ford Probe (1996-1997)
