(888) 312-8812 Login SignupDELPHI GN10305 Ignition Coil
$8299
Limited availability at this price!
1 Day Lead Time
Get it by Monday, Feb 23
DELPHI GN10305 Part Description
Manufacturer
Product Description
Ignition Coil
Features & Benefits
- Delphi coils provide OE performance, durability and electromagnetic capacity level requirements
- Delphi ignition coils are designed to insert power into spark plugs to ensure fast starts, consistent engine performance and optimized fuel efficiency
- Delphi uses smart winding process techniques to controls wire lengths, keeping voltage the same
- We manufacture our ignition coils with a high quality wire coating that resists imperfections that lead to failure
DELPHI GN10305 Specifications
Product Attributes
| Package Contents | Ignition Coil |
| Ignition Type | Electronic |
| Coil Type | Coil On Plug Ignition |
| Coil Wire Included | No |
| Oil Filled | No |
| Requires External Resistor | No |
| Terminal Type | Blade |
| Mounting Hardware Included | No |
| Wire Quantity | 0 |
| Grade Type | Standard Replacement |
| Mount Type | 2 Mounting Holes |
| Mounting Hole Quantity | 2 |
| Secondary Resistance | 11400.0 82 |
| Terminal Quantity | 3 |
| Connector Gender | Female |
| Terminal Gender | Male |
| Voltage | 12.0 2H |
| Length | 3.366 IN |
| Width | 1.878 IN |
| Height | 6.177 IN |
| Length | 85.5 MM |
| Width | 47.7 MM |
| Height | 156.9 MM |
| Color | Black |
| Connector Quantity | 1 |
| Connector Shape | Rectangular |
Additional Information
| Harmonized Tariff Code (HTS) | 8511300080 |
| Warranty Distance UOM | DH |
| Warranty Distance | 36000 |
| Harmonized Tariff Code (Schedule B) | 8511300080 |
| Warranty Time UOM | MO |
| Warranty Time | 36 |
| Country of Origin (Primary) | CN |
| UPC | 00689604218501 |
| VMRS Code | 033003001 |
| UNSPSC | 26101769 |
DELPHI GN10305 Cross References
| Brand | Part Number |
|---|---|
| Airtex | 5C1159 |
| BWD | E912 |
| Beck/Arnley | 178-8287 |
| BorgWarner | E912 |
| Carquest | 26C1077, 52-1714 |
| DENSO | 673-8202 |
| DENSO Auto Parts | 673-8202 |
| Duralast | C1353 |
| ENCORE AUTOMOTIVE | IC-K10018 |
| Echlin | IC552 |
| HITACHI | IGC0155 |
| HOLSTEIN | 2IGC0318 |
| Hyundai | 27300-39000, 27300-39050 |
| IMC | CLS1041 |
| Import Direct | 23-0469 |
| Karlyn | 5032 |
| Kia | 27300-39050 |
| MasterPro Ignition | 2-50028 |
| N/A | 521714, 2730039000, 2730039050, 72928002, 355P, 1788287, UF432, 921X2028 |
| NAPA Mileage Plus | IC552SB |
| NGK | U4023 |
| NGK SPARK PLUGS | U4023, 48920 |
| NTK | U4023 |
| Original Engine Management | 50028 |
| PRENCO | 36-2040, 36-8143 |
| STANDARD IGNITION | UF-432 |
| Spectra Premium | C-658 |
| Standard Import | E912 |
| Standard Motor Products | UF-432T, UF-432 |
| WPS World Power Systems | CUF432 |
| Walker Products | 921-2028 |
| Wells | C1353 |
DELPHI GN10305 Fits Vehicles
- Kia Sedona (2002-2005)
- Hyundai XG350 (2002)
- Hyundai XG300 (2001)
