(888) 312-8812 Login SignupDELPHI HP10152 Fuel Pump Hanger Assembly
$10449
Limited availability at this price!
In Stock
Get it by Tuesday, Aug 4
DELPHI HP10152 Part Description
Manufacturer
Product Description
Fuel Pump Hanger Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Delphi pumps are designed to operate under extreme temperatures with quick engine starts
- Metal tubes in Delphi hangers are routed so as to not contact the tank at any point eliminating noise and vibration during vehicle operation
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Restores fast pressure performance and system integrity, translating to better pumping through less energy
- Lower failure rates due to its innovative design and durability
- Part is validated, tested and matched to the right vehicle application
- Lower amperage draws less load on vehicle's electrical system
- Always be sure to check and clean fuel tank to avoid unnecessary returns
DELPHI HP10152 Specifications
Product Attributes
| Package Contents | Fuel Pump Hanger Assembly w/Float Arm, Seal, Lock Ring, Instruction Sheet |
| Item Grade | Standard Replacement |
| System Pressure | 51 psi |
| Fuel Level Sender Assembly Included | Yes |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 12.0 2H |
| Fuel Type | Gas |
| Maximum Pressure | 73.0 PS |
| Terminal Type | Pin |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 2 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 10.0 82 |
| Resistance Ohms Full | 160.0 82 |
| Internal Or External Strainer | External |
| Pump Type | Electric |
| Average Current Draw | 7.0 68 |
| Average Flow Rating | 22.0 GPH |
| Material | Metal |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Shape | Oval |
| Lock Ring Included | Yes |
| Connector Gender | Female |
| Inlet Quantity | 1 |
| Fuel Pump Included | Yes |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 51 PS |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | No |
| Universal Or Specific Fit | Specific |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Harmonized Tariff Code (HTS) | 9026102080 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | MX |
| UPC | 00689604218648 |
| VMRS Code | 044003257 |
| UNSPSC | 40151532 |
DELPHI HP10152 Cross References
| Brand | Part Number |
|---|---|
| AUTOBEST | F1112A |
| Airtex | E2001, E2065, E2101S, E2471 |
| AutoZone | DHP10152 |
| Bosch | 67032, 69125 |
| CARTER FUEL PUMPS | P74626H |
| Carter | P74092, P74122, P74145, P74626H |
| DENSO Auto Parts | 950-3010, 951-0016 |
| EVO Driveline | AFS0029P, AFS0059S, RE0029P, RE0059S |
| Ford | E83Z 9H307-B, E83Z 9H307-F, F43Z 9A407-AA |
| GMB | 525-6017 |
| Motorcraft | PFB-32 |
| N/A | E83Z9H307B, E83Z9H307F, F43Z9A407AA, USEP2101S, B0023H, 4011075, 4017044 |
| Precision Fuel | A20013, E16006 |
| Spectra Premium | SP1113, SP1142, SP1172, SP235H |
DELPHI HP10152 Fits Vehicles
- Mercury Topaz (1988-1994)
- Ford Tempo (1988-1994)
