(888) 312-8812 Login SignupDELPHI HP10143 Fuel Pump Hanger Assembly
MSRP: $140.66
$12049
Save $20.17
Limited availability at this price!
In Stock
Get it by Wednesday, Jul 1
DELPHI HP10143 Part Description
Manufacturer
Product Description
Fuel Pump Hanger Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Delphi pumps are designed to operate under extreme temperatures with quick engine starts
- Metal tubes in Delphi hangers are routed so as to not contact the tank at any point eliminating noise and vibration during vehicle operation
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Restores fast pressure performance and system integrity, translating to better pumping through less energy
- Lower failure rates due to its innovative design and durability
- Part is validated, tested and matched to the right vehicle application
- Lower amperage draws less load on vehicle's electrical system
- Always be sure to check and clean fuel tank to avoid unnecessary returns
DELPHI HP10143 Specifications
Product Attributes
| Package Contents | Fuel Pump Hanger Assembly w/Float Arm, Seal, Lock Ring, Instruction Sheet |
| Item Grade | Standard Replacement |
| Fuel Level Sender Assembly Included | Yes |
| System Pressure | 44 psi |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 12.0 2H |
| Fuel Type | Gas |
| Maximum Pressure | 80.0 PS |
| Terminal Type | Pin |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 2 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 15.0 82 |
| Resistance Ohms Full | 160.0 82 |
| Internal Or External Strainer | External |
| Pump Type | Electric |
| Average Current Draw | 7.0 68 |
| Average Flow Rating | 25.0 GPH |
| Material | Metal |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Shape | Oval |
| Lock Ring Included | Yes |
| Connector Gender | Female |
| Inlet Quantity | 1 |
| Fuel Pump Included | Yes |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 44 PS |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | No |
| Universal Or Specific Fit | Specific |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Harmonized Tariff Code (HTS) | 9026102080 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | MX |
| UPC | 00689604215258 |
| VMRS Code | 044003257 |
| UNSPSC | 40151532 |
DELPHI HP10143 Cross References
| Brand | Part Number |
|---|---|
| AUTOBEST | F1009A |
| Airtex | E2044, E2098S |
| AutoZone | DHP10143 |
| Bosch | 67029, 67280, 69118 |
| CARTER FUEL PUMPS | P74651S |
| Carter | P74118, P74149, P74651S |
| DENSO Auto Parts | 950-3014 |
| EVO Driveline | AFS0017P, AFS0056S, RE0017P, RE0056S |
| Ford | E9SZ 9H307-C, F1SZ 9H307-BA, F1SZ 9H307-CA, F5SZ 9H307-BA, F6SZ 9H307-AB |
| GMB | 525-6430 |
| Motorcraft | PFS-177, PFS-178, PFS-181, PFS-184, PFS-185 |
| N/A | E9SZ9H307C, F1SZ9H307BA, F1SZ9H307CA, F5SZ9H307BA, F6SZ9H307AB, USEP2098S, 402-P2098S, C0021H, 4010013 |
| Precision Fuel | A27027, E16047 |
| Spectra Premium | SP1140, SP2098H |
DELPHI HP10143 Fits Vehicles
- Mercury Cougar (1989-1997)
- Ford Thunderbird (1989-1997)
