(888) 312-8812 Login SignupDELPHI FG1350 Fuel Pump Module Assembly
$46699
Limited availability at this price!
In Stock
Get it by Thursday, Dec 18
DELPHI FG1350 Part Description
DELPHI FG1350 Specifications
Product Attributes
| Vapor Pressure Sensor | No |
| System Pressure | 44 psi |
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Lock Ring, Instruction Sheet |
| Item Grade | Standard Replacement |
| Fuel Level Sender Assembly Included | Yes |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 12 2H |
| Fuel Type | Gas |
| Regulator Included | Yes |
| Maximum Pressure | 80 PS |
| Terminal Type | Blade |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 6 |
| Lock Ring Included | Yes |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 3 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 53 82 |
| Resistance Ohms Full | 1 82 |
| Internal Or External Strainer | External |
| Pump Type | Electric |
| Average Current Draw | 8 68 |
| Average Flow Rating | 30 GPH |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Quantity | 1 |
| Connector Shape | Rectangle |
| Housing Material | Plastic |
| Installation Warnings | No |
| Connector Gender | Female |
| Fuel Filter Included | Yes |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 44 PS |
| Wire Harness Included | No |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | No |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TH |
| UPC | 00689604233146 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
DELPHI FG1350 Part Interchanges
| Brand | Part Number |
|---|---|
| N/A | 42021AE02A, 42021AE02B, P76524M, USEP8596M, C0611M |
| Bosch | 69709 |
| DENSO Auto Parts | 951-0007 |
| Spectra Premium | SP1118, SP4039M, SP4040M |
| Carter | P76249, P76529M |
| AutoZone | CFG1350 |
| Subaru | 42021 AE02A, 42021 AE02B, 42021 AE05A, 42021 AE05B |
| Airtex | E8229, E8454, E8596M, E8596MN, E8600MN |
| Import Direct | A30282, E16009, E16014 |
DELPHI FG1350 Fits Vehicles
- Subaru Outback (2000-2004)
- Subaru Legacy (2000-2003)
- Subaru Baja (2003)
