DELPHI FG1340 Fuel Pump Module Assembly

★★★★★ (0)

$287.99

Limited availability at this price!

In Stock

Get as soon as Wednesday, Nov 25
30-day Return Policy On eligible items Details
Free Ground shipping on orders over $499 details
Orders placed over the weekend will be processed the next business day.

DELPHI FG1340 Part Description

Manufacturer

DELPHI

Product Description

Fuel Pump Module Assembly

Features & Benefits

  • Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
  • Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
  • Lower amperage draws less load on vehicle's electrical system
  • Part is validated, tested and matched to the right vehicle application
  • Always be sure to check and clean fuel tank to avoid unnecessary returns
  • Lower failure rates due to its innovative design and durability

DELPHI FG1340 Specifications

Product Attributes

Position(s)Right
Fuel Level Sender Assembly IncludedYes
System Pressure44 psi
Vapor Pressure SensorNo
Item GradeStandard Replacement
Package ContentsFuel Pump Module Assembly w/Float Arm, Seal, Instruction Sheet
Outlet Outside Diameter0.313 IN
Voltage12 2H
Fuel TypeGas
Regulator IncludedYes
Maximum Pressure80 PS
Terminal TypePin
Gasket Or Seal IncludedYes
Terminal Quantity4
Lock Ring IncludedNo
Terminal GenderMale
Strainer IncludedYes
Inlet TypeStrainer
Outlet TypeFemale Push In
Outlet Quantity2
In Tank or ExternalIn Tank
Resistance Ohms Empty15 82
Resistance Ohms Full160 82
Internal Or External StrainerExternal
Pump TypeElectric
Average Current Draw8 68
Average Flow Rating31 GPH
Fuel Sending Unit IncludedYes
Negative GroundNo
Mounting Hardware IncludedNo
Grade TypePremium
Connector Quantity1
Connector ShapeRound
Housing MaterialPlastic
Installation WarningsNo
Connector GenderFemale
Fuel Filter IncludedNo
Gasket Or Seal MaterialNitrile Rubber
Minimum Pressure44 PS
Wire Harness IncludedNo
Pump DesignTurbine
Fuel Tank Pressure Sensor IncludedNo
Universal Or Specific FitSpecific

Additional Information

Harmonized Tariff Code (HTS)9026102080
Warranty SpecialLimited
Warranty Special UOMLT
Harmonized Tariff Code (Schedule B)8413309000
Country of Origin (Primary)TH
UPC00689604233047
VMRS Code044003258
UNSPSC25172409

DELPHI FG1340 Cross References

BrandPart Number
AirtexE2314
AutoZoneCFG1340
Bosch67244
CarterP74937M
EVO DrivelineAFS0967P, RE0837S
FordXW4Z 9H307-AA, YW4Z 9H307-BB
GMB525-2095
MotorcraftPFS-245
N/AXW4Z9H307AA, YW4Z9H307BB, USEP2274M, E2322M, C0784M, 4010254
Precision FuelA30550, E16028
Spectra PremiumSP1134, SP2322M
UROXR8 22164

DELPHI FG1340 Fits Vehicles

  • Ford Thunderbird (2002)
  • Jaguar S-Type (2000-2002)
  • Lincoln LS (2000-2002)
