(888) 312-8812 Login SignupDELPHI FG1055 Fuel Pump Module Assembly
MSRP: $469.23
$32899
Save $140.24
Limited availability at this price!
In Stock
Get it by Monday, Feb 16
DELPHI FG1055 Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Lower amperage draws less load on vehicle's electrical system
- Part is validated, tested and matched to the right vehicle application
- Always be sure to check and clean fuel tank to avoid unnecessary returns
- Lower failure rates due to its innovative design and durability
DELPHI FG1055 Specifications
Product Attributes
| Fuel Type | Flex |
| Vapor Pressure Sensor | Yes |
| Fuel Level Sender Assembly Included | Yes |
| Item Grade | Standard Replacement |
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Seal, Instruction Sheet |
| System Pressure | 73 psi |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 12 2H |
| Regulator Included | Yes |
| Maximum Pressure | 78 PS |
| Terminal Type | Blade |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Lock Ring Included | No |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 2 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 250 82 |
| Resistance Ohms Full | 40 82 |
| Internal Or External Strainer | Internal |
| Pump Type | Electric |
| Average Current Draw | 11 68 |
| Average Flow Rating | 20 GPH |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Fuel Type | Flex |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Quantity | 1 |
| Connector Shape | Oval |
| Housing Material | Plastic |
| Installation Warnings | No |
| Connector Gender | Female |
| Fuel Filter Included | Yes |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 73 PS |
| Wire Harness Included | No |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | Yes |
| Universal Or Specific Fit | Specific |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TH |
| UPC | 00689604215876 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
DELPHI FG1055 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | MU1845, M100063, M100094, M10133, M10205, MU1844, MU2092, MU2135, SK1310 |
| Airtex | E3797M |
| AutoZone | CFG1055 |
| CARTER FUEL PUMPS | P76699M |
| CONTINENTAL AG | FP22053S |
| Carquest | M2496234 |
| Carter | P76292M, P76699M |
| GMB | 530-2905 |
| General Motors | 19206481, 19259394, 19168707, 19206477, 19299715, 19168708, 19206479, 19257106 |
| N/A | FG1055, USEP3797M, F2708A, C0299M, C0300M, 4010690 |
| Precision Fuel | A30312, A33115 |
| Spectra Premium | SP6631M |
| TYC | 150360-A |
| VDO | FP22053S |
| VEMO | V51090014 |
DELPHI FG1055 Fits Vehicles
- Cadillac Escalade EXT (2009-2013)
- Cadillac Escalade ESV (2009-2014)
- Chevrolet Suburban 1500 (2008-2014)
- GMC Yukon XL 1500 (2008-2014)
- Chevrolet Avalanche (2008-2013)
