Name: Delphi FG0862 Fuel Pump Module Assembly
SKU: fg0862
Price: 307.49 USD
Availability: InStock

Fuel Pump Module Assembly

Fuel Level Sender Assembly Included	Yes
Package Contents	Fuel Pump Module Assembly w/Float Arm, Seal, Instruction Sheet
Vapor Pressure Sensor	No
Item Grade	Standard Replacement
System Pressure	44 psi
Outlet Outside Diameter	0.375 IN
Voltage	12 2H
Fuel Type	Gas
Regulator Included	Yes
Maximum Pressure	80 PS
Terminal Type	Pin
Gasket Or Seal Included	Yes
Terminal Quantity	4
Lock Ring Included	No
Terminal Gender	Male
Strainer Included	Yes
Inlet Type	Strainer
Outlet Type	Quick Connect
Outlet Quantity	2
In Tank or External	In Tank
Resistance Ohms Empty	15 82
Resistance Ohms Full	160 82
Internal Or External Strainer	External
Pump Type	Electric
Average Current Draw	7 68
Average Flow Rating	23 GPH
Fuel Sending Unit Included	Yes
Negative Ground	No
Mounting Hardware Included	No
Grade Type	Premium
Connector Quantity	1
Connector Shape	Round
Housing Material	Plastic
Installation Warnings	No
Connector Gender	Female
Fuel Filter Included	No
Gasket Or Seal Material	Nitrile Rubber
Minimum Pressure	44 PS
Wire Harness Included	No
Pump Design	Turbine
Fuel Tank Pressure Sensor Included	No

Harmonized Tariff Code (Schedule B)	8413309000
Harmonized Tariff Code (HTS)	8413309030
Warranty Special	Limited Lifetime
Warranty Special UOM	LF
Country of Origin (Primary)	TH
UPC	00689604202944
VMRS Code	044003258
UNSPSC	25172409
