Champion 569 - Industrial / Agriculture™ Spark Plug
$1249
MSRP: $17.23
Save: $4.74
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CHAMPION part description
Product Description
Spark Plug W14 Carton of 8
Application Summary
INDUSTRIAL, SMALL ENGINE, TRACTOR, VINTAGE
Features & Benefits
- Designed for high compression and aggressive environments
- Manufactured for long-lasting durability
- Backed by global engineering from Federal-Mogul
- Superior performance and long lasting durability
Product Attributes
| Ground Electrode Core Material | Nickel |
| Washer(s) Included | Yes |
| Center Electrode Tip Material | Nickel |
| Pre-Gap Size | 0.028 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 0.938 IN |
| Manufacturer Heat Range | 14 |
| Seat Type | Flat |
| Reach | 0.625 IN |
| Thread Diameter | 0.875 IN |
| Resistor Type | No |
| Hex Type | Hex |
| Washer Type | Crush |
| Indexed | No |
| Center Electrode Diameter (inch) | 0.125 IN |
| Classification | Champion Agricultural Plugs |
| Ground Electrode Material | Nickel Copper Alloy |
| Installed Height (inch) | 2.57 IN |
| Part Description | Spark Plug |
| Plug Type | W14 |
| Taper Diameter (inch) | 0.42 IN |
| Pre-Gap Size | 0.71 MM |
| Hex Size | 23.830 MM |
| Thread Diameter | 22.225 MM |
| Title | Champion Indust. / Agri Plugs- Boxed - W14 |
| Ground Electrode Tip Material | Nickel |
| Center Electrode Design | Standard |
| Grade Type | Premium |
| Subject To Prop 65 (yes/no) | No |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8511100000 |
| Harmonized Tariff Code (HTS) | 8511100000 |
| Refurbished Part | N |
| Remanufactured Part | N |
| UPC | 00037551001330 |
| VMRS Code | 033003005 |
Part Interchanges
- Champion Spark Plug W14
- ACDelco C75
- Prestolite 78-10
- Prestolite 78-8
- Motorcraft TT10
- Motorcraft TT8
- Caterpillar 2B9548
- Stitt 147B
- Autolite 3076
- Bosch Z45T4
- Champion Spark Plug 1
- Champion Spark Plug 1COM
- Champion Spark Plug A43
- Champion Spark Plug C0
- Champion Spark Plug C5
- Autolite 3075
- NGK 3320
- NGK G2Z
- Prestolite 7810
- Prestolite 788
- ACDelco 74
- ACDelco 75Com
- John Deere AL2005T
- Kubota 1026167716
- Stitt 7H
Fits Vehicles
- Studebaker L5 (1939)
- Studebaker K5 Truck (1938)
- Studebaker J5 (1937)
- Rockne Model 65 (1932)
- Rockne Model 75 (1932)
- Maxwell Model 35 (1914)
- Maxwell Model 30 (1913)
- Maxwell Model 22 (1913)
- Lexington Model 6-50 (1926-1927)
- Maxwell Six (1913)
- Lexington Minute Man (1924-1925)
- Lexington Model 23 (1923)
- Maxwell Model 25 (1914-1923)
- Maxwell Model 50 (1914)
- Maxwell Model 40 (1913)
- Lexington Concord (1924-1925)
- HCS Series II (1920-1921)
- HCS Series VI (1923-1924)
- HCS Series III (1922)
- Haynes Model 60 (1923-1925)
- HCS Series IV (1923-1924)
- Apperson Six (1925-1926)
- Studebaker Dictator (1927-1928)
