(888) 312-8812 Login SignupRAYBESTOS 981010 Raybestos Specialty - Truck Coated Brake Rotor
$115.86
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 981010 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Coated Brake Rotor
Application Summary
2020-2014 Kia Sorento Front, 2018-2013 Hyundai Santa Fe Sport Front, 2018-2013 Hyundai Santa Fe Front, 2019-2014 Hyundai Santa Fe XL Front
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 981010 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.72 IN |
| Center Hole Diameter | 69.1 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.024 IN |
| Discard Thickness | 26 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 8.067 IN |
| Inside Diameter | 204.9 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.496 IN |
| Mounting Bolt Hole Diameter | 12.6 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.106 IN |
| Nominal Thickness | 28.1 MM |
| Outside Diameter | 12.598 IN |
| Outside Diameter | 320 MM |
| Overall Height | 1.941 IN |
| Overall Height | 49.3 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213080193 |
RAYBESTOS 981010 Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH536734, YH536734C, YH536734P |
| AUTOPARTSOURCE | 483291 |
| AUTOXTRA | AX901184 |
| AUTOZONE | 70119DG, 70119DL, 70128DG, 70128DL |
| Advance Auto Parts | YH479087P |
| Autoxtra | AX901184P |
| BENDIX | PRT6234 |
| BRAKEBEST | 981010, 981010FZN, 981010R, 981010RGS |
| BrakeBest | 921828RGS |
| Brembo | 09.E237.11 |
| CENTRIC | 120.50034, 121.50034, 125.50034, 126.50034SL, 126.50034SR, 127.50034L, 127.50034R, 128.50034L, 128.50034R, 120.51052 |
| Centric Parts | 120.50034, 121.50034, 125.50034, 126.50034SL, 126.50034SR, 127.50034L, 127.50034R, 128.50034L, 128.50034R, 120.51052, 121.51052, 126.51052CSL, 126.51052CSR, 126.51052SL, 126.51052SR, 127.51052L, 127.51052R, 128.51052L, 128.51052R, 320.51052 |
| DURA CORP | BR901184, BR90118402 |
| DuraGo | BR901184, BR90118402, BR901184-02 |
| Dynamic Friction Company | 600-21030, 600-03053 |
| Hyundai | 517122W000 |
| KIA | 517124Z000, 51712C6000 |
| MAGMA PRODUCTS | PSR285091 |
| NEOTEK | 1069044GF |
| NEWTEK AUTOMOTIVE | R1184 |
| Newtek Automotive USA | R1184 |
| Omnicraft | QBRR616 |
| POWERSTOP | JBR1585EVC, JBR1706EVC |
| Qualis | 44764, 44884 |
| TopNotch | TN981010GEO |
| UAP | 2940828 |
| Ultra Brake | HY-3013 |
| WAGNER | BD180591E |
| WAGNER BRAKE | BD180591 |
| WORLDPAC | 1407-479087, 1407-536734, 1427-613621, 1427-613651 |
| Wagner Brake | BD180591E |
| Winhere | 6621553, 6621828 |
RAYBESTOS 981010 Fits Vehicles
- Hyundai Santa Fe Sport (2013-2018)
- Hyundai Santa Fe XL (2013-2019)
- Kia Sorento (2014-2020)
- Hyundai Santa Fe (2012-2019)
