RAYBESTOS 780960 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
2020-2012 Jeep Grand Cherokee Front, 2020-2018 Dodge Durango Front
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 780960 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.835 IN |
| Center Hole Diameter | 72 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.26 IN |
| Discard Thickness | 32 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 9.535 IN |
| Inside Diameter | 242.2 MM |
| Mounting Bolt Hole Circle Diameter | 5 IN |
| Mounting Bolt Hole Circle Diameter | 127 MM |
| Mounting Bolt Hole Diameter | 0.673 IN |
| Mounting Bolt Hole Diameter | 17.1 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.339 IN |
| Nominal Thickness | 34 MM |
| Outside Diameter | 14.961 IN |
| Outside Diameter | 380 MM |
| Overall Height | 2.15 IN |
| Overall Height | 54.6 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213014600 |
RAYBESTOS 780960 Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH421771P |
| AUTOZONE | 72213, 72213DG, 72213DL |
| BENDIX | PRT6172 |
| BRAKEBEST | 780960, 780960FZN, 780960R, 780960RGS |
| Brembo | 09.N246.21 |
| CENTRIC | 120.58010, 120.58010CRY, 120.58010S, 121.58010, 126.58010SR, 126.58010, 126.58010CSL, 126.58010CSR, 126.58010SL, 127.58010L, 127.58010R, 128.58010L, 128.58010R, 226.58010, 320.58010F |
| CHRYSLER | 05181513AB, 05181513AD, 5181513AA, 5181513AB, 5181513AC, 5181513AD |
| Centric Parts | 120.58010, 120.58010CRY, 120.58010S, 121.58010, 126.58010, 126.58010CSL, 126.58010CSR, 126.58010SL, 126.58010SR, 127.58010L, 127.58010R, 128.58010L, 128.58010R, 226.58010, 320.58010F |
| DURA CORP | BR53066 |
| Dura Corp | BR901578 |
| DuraGo | BR901578 |
| MAGMA PRODUCTS | PSR145200 |
| MONROE BRAKES | BD180434 |
| NEOTEK | 107331GF |
| NEWTEK AUTOMOTIVE | 53066 |
| Newtek Automotive USA | 53066 |
| PROMAX | 14-53066 |
| Qualis | 43181, 63203 |
| UAP | R58010 |
| WAGNER | BD180682E |
| WAGNER BRAKE | BD180434 |
| WORLDPAC | 1407-421771, 1427-524002 |
| WORLDPARTS | WS1-153066 |
| Wagner Brake | BD180500, BD180682E |
| Winhere | 6621372SL |
RAYBESTOS 780960 Fits Vehicles
- Dodge Durango (2017-2020)
- Jeep Grand Cherokee (2012-2020)
