Raybestos 681016 - CL12-BRAKE ROTO
$25599
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
RAYBESTOS part description
Product Description
Raybestos Specialty - Truck Coated Brake Rotor
Application Summary
2022-2013 Ford F-250 Super Duty Front, 2022-2013 Ford F-350 Super Duty Front, 2016-2013 Ford F-450 Super Duty Front
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 5.08 IN |
| Center Hole Diameter | 129.05 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.433 IN |
| Discard Thickness | 36.4 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 9.094 IN |
| Inside Diameter | 231 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 6.752 IN |
| Mounting Bolt Hole Circle Diameter | 171.5 MM |
| Mounting Bolt Hole Diameter | 0.636 IN |
| Mounting Bolt Hole Diameter | 16.15 MM |
| Mounting Bolt Hole Quantity | 8 |
| Nominal Thickness | 1.515 IN |
| Nominal Thickness | 38.5 MM |
| Outside Diameter | 14.293 IN |
| Outside Diameter | 363.05 MM |
| Overall Height | 3.94 IN |
| Overall Height | 100.1 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 8 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| UPC | 00887213083705 |
Part Interchanges
- Ford DC3Z1125A
- Ford HC3Z1125B
- Wagner Brake BD180661E
- BrakeBest 672355RGS
- BrakeBest 681016
- BrakeBest 681016R
- Centric Parts 120.65138
- Centric Parts 121.65138
- Centric Parts 126.65138CSL
- Centric Parts 126.65138CSR
- Centric Parts 126.65138SL
- Centric Parts 126.65138SR
- Centric Parts 127.65138L
- Centric Parts 127.65138R
- Centric Parts 320.65138F
- AutoZone 75017
- AutoZone 75017DG
- Advance Auto Parts YH482052P
- Advance Auto Parts YH507781P
- Autoxtra AX901170
- Dura Corp BR901170
- Newtek Automotive USA 54198
- Newtek Automotive USA R1170
- Promax 14-54198
- UAP 2901170
- UAP R65138
- Centric Parts 320.65138
- Dynamic Friction Company 600-54223
- Advance Auto Parts G15587SD
- DuraGo BR901170
- Parts Master 901170
- Motorcraft BRRF465
- Qualis 42292
- Ford PC3Z1125A
RAYBESTOS 681016 Cross Reference
We have 27 alternatives for the 681016 by RAYBESTOS:
- FORD DC3Z1125A
- FORD HC3Z1125B
- ADVANCE AUTO PARTS YH482052P
- ADVANCE AUTO PARTS YH507781P
- AUTOXTRA AX901170
- AUTOZONE 75017
- AUTOZONE 75017DG
- BRAKEBEST 672355RGS
- BRAKEBEST 681016
- BRAKEBEST 681016R
- CENTRIC 120.65138
- CENTRIC 121.65138
- CENTRIC 126.65138CSL
- CENTRIC 126.65138CSR
- CENTRIC 126.65138SL
- CENTRIC 126.65138SR
- CENTRIC 127.65138L
- CENTRIC 127.65138R
- CENTRIC 320.65138
- CENTRIC 320.65138F
- DURA CORP BR901170
- NEWTEK AUTOMOTIVE 54198
- NEWTEK AUTOMOTIVE R1170
- PROMAX 14-54198
- UAP 2901170
- UAP R65138
- WAGNER BRAKE BD180661E
Fits Vehicles
- Ford F-450 Super Duty (2013-2016)
- Ford F-350 Super Duty (2013-2023)
- Ford F-250 Super Duty (2013-2023)
