(888) 312-8812 Login SignupDELPHI FG0175 Fuel Pump Module Assembly
MSRP: $566.01
$9099
Save $475.02
Limited availability at this price!
In Stock
Get it by Friday, Dec 26
DELPHI FG0175 Part Description
DELPHI FG0175 Specifications
Product Attributes
| Vapor Pressure Sensor | No |
| Item Grade | Standard Replacement |
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Instruction Sheet |
| Fuel Level Sender Assembly Included | Yes |
| System Pressure | 43 psi |
| Position(s) | Right |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 12 2H |
| Fuel Type | Gas |
| Regulator Included | No |
| Maximum Pressure | 73 PS |
| Terminal Type | Blade |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Lock Ring Included | No |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 2 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 125 82 |
| Resistance Ohms Full | 20 82 |
| Internal Or External Strainer | Internal |
| Pump Type | Electric |
| Average Current Draw | 10 68 |
| Average Flow Rating | 20 GPH |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Quantity | 1 |
| Connector Shape | Oval |
| Housing Material | Plastic |
| Installation Warnings | No |
| Connector Gender | Female |
| Fuel Filter Included | No |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 43 PS |
| Wire Harness Included | No |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | No |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604061121 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
DELPHI FG0175 Part Interchanges
| Brand | Part Number |
|---|---|
| General Motors | 22690014, 22716735, 25335259 |
| ACDelco | MU273, 22716735 |
| Carter | P76239M |
| Airtex | E3585M |
| Spectra Premium | SP6278M, SP3585M |
| AutoZone | DFG0175 |
| EVO Driveline | AFS0958S |
| Precision Fuel | A30305 |
| N/A | USEP3585M, F2496A |
DELPHI FG0175 Fits Vehicles
- Saturn Vue (2002-2003)
DELPHI FG0175 Cross References
We have 1 alternatives for the FG0175 by DELPHI:
