AUTOLITE XS63 Part Description
Manufacturer
Product Description
Autolite XS63 Xtreme Sport Iridium Powersports Spark Plug
Features & Benefits
- Design to withstand the extreme operating temperatures experienced during a power sports engine's combustion.
- Engineered with an iridium-enhanced fine-wire center electrode that delivers greater ignitability over standard non-fine-wire spark plug.
- 0.6mm finewire design with Sport V-trim ground electrode for more horsepower than standard plug
- The tapered ground electrode provides improved ignitability for more efficient and smoother starts.
- Up to 26% quicker engine starts than a standard non-finewire spark plug* (* Testing performed by independent lab)
- Its high alumina multi-rib ceramic insulator provides thermal conductivity and superior insulation for increased strength.
- Focused ignition prevents fouling better than leading standard plug for reliable starting in any season or weather
AUTOLITE XS63 Specifications
Product Attributes
| Resistance | 4000 82 |
| Ground Electrode Tip Design | Taper Cut |
| Ground Electrode Core Material | Nickel |
| Electrical Terminal Type | Non-Removable Nut |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Iridium |
| Pre-Gap Size | 0.034 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 21 MM |
| Seat Type | Flat |
| Reach | 0.75 IN |
| Thread Diameter | 14 MM |
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| Ground Electrode Tip Material | Nickel |
| Center Electrode Design | Fine Wire |
| Center Electrode Projection | Mid Projection |
| Washer(s) Included | Yes |
| Grade Type | Performance |
| Hex Size | 13/16 IN |
| Manufacturer Heat Range | 10 |
| Skirt | Yes |
| Hex Type | Hex |
| Indexed | No |
| Reach | 19.049999999999997 MM |
| Pre-Gap Size | 0.9 MM |
| Thread Type Standard | Metric |
| Thread Size | M14 - 1.25 |
| Washer Type | Crush |
| Thread Diameter | 14 MM |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8511100000 |
| Warranty Special | No Warranty |
| Warranty Special UOM | TX |
| Harmonized Tariff Code (HTS) | 8511100000 |
| UPC | 00009100261533 |
| UNSPSC | 26101732 |
AUTOLITE XS63 Cross References
| Brand | Part Number |
|---|---|
| ACCEL | 114, 494 |
| ACDelco | 42XLS, R41XLS, R42CXLS, R42XLS, R42XLS6 |
| Atlas Spark Plugs | C88R |
| Beck/Arnley | 176-5310 |
| Beru | 14 GH-7 DTUR, 14 R-6 DU, 14 R-6 DUX, 14 R-7 DU, 14 R-7 DUX, 14-6 DTU, 14-6 DU, 14-6 DUO, 14-7 DTU, 14-7 DU, 14-7 DUO, UX 79 |
| Champion Spark Plug | 300, RN10WYPB5 |
| DENSO Auto Parts | 3027, IW20TT, W20EPR-S11 |
| E3 | E3.30 |
| E3 SPARK PLUGS | E334 |
| Mopar | SP000RN9YC |
| Motorcraft | AG12, AG12C, AG22, AG22C, AGR12, AGR22, AGR22C, AGS12C, AGS22C, SP402, SP664 |
| NGK | 913, BKR6EIX-11, BP7EIX, BP7EIX-11, BPR6EIX, BPR6EIX-11 |
| NGK SPARK PLUGS | BPR6EIX, 6637 |
| Splitfire - Archived | SF425C, SF426C, SF6C, SM6C |
| Suzuki | 09482-00299, 0948200299 |
| Tennant | 45770-8, 457708 |
| Torch | F6RF, F6RTC, F6RTC-11, F6T, F6TC, F7RTC, F7RTJC, F7TC, F7TJC |
AUTOLITE XS63 Fits Vehicles
- Suzuki Aerio (2002)
- Yamaha SR400 (2015-2018)
- Sea-Doo GSI (1997)
- Kawasaki JS750 750SXi (1995-1996)
- Arctic Cat Sno Pro 120 (2010-2013)
- Moto Guzzi Norge 1200 (2008-2009)
- Moto Guzzi Griso 1100 (2005-2008)
- Moto Guzzi Breva 1100 (2006-2008)
- Arctic Cat AC 120 Sno Pro (2007-2009)
- Arctic Cat F120 (2006)
- Sea-Doo GTI LE (2002-2004)
- Gas Gas Pampera 280 (2002-2005)
- Arctic Cat ZR 120 (2002-2005)
- Kawasaki JT900 900STS (2001-2002)
- Arctic Cat Z 120 Sno Pro (2001)
- Arctic Cat Z 120 (2000-2001)
- Ski-Doo Mini Z (1998-2008)
- Kawasaki JH750 Xi Sport (1998-1999)
- Kawasaki JT750 750STX (1998)
- Kawasaki JS750 SXI Pro (1998-2002)
- Sea-Doo GS (1997-2001)
- Sea-Doo GTS (1997-2001)
- Kawasaki JT900 900STX (1997-2006)
- Kawasaki JT1100 1100STX (1997-1999)
- Sea-Doo GTI (1996-2005)
- Kawasaki JH1100 1100ZXi (1996-2003)
- Gas Gas Pampera 250 (1996)
- Sea-Doo HX (1995-1997)
- Kawasaki JH900 900ZXi (1995-1997)
- Kawasaki JT750 STS (1995-1997)
- Kawasaki JH750 750ZXi (1995-1997)
- Yamaha VX500DX VMAX 500 DX (1994-1995)
- Yamaha VX500ST VMAX 500 ST (1994)
- Yamaha VX500 VMAX 500 (1994-1995)
- Yamaha VX500E VAMX 500 LE (1994-1995)
- Kawasaki JT750 ST (1994-1995)
- Kawasaki JH750 XiR (1994)
- Yamaha EX570SX Exciter II SX (1993)
- Yamaha EX570ST Exciter II ST (1993)
- Kawasaki JH750 Super Sport XI (1993-1997)
- Kawasaki JS750 750SX (1992-1995)
- Kawasaki JH750 750SS (1992-1997)
- BMW R100R (1992-1995)
- Yamaha EX570 Exciter II (1991-1993)
- Yamaha EX570E Exciter II LE (1991-1993)
- Kawasaki JL650 SC (1991-1995)
- Yamaha EX570E Exciter LE (1990)
- Yamaha EX570H High Altitude (1990)
- Kawasaki JS550 550SX (1990-1995)
- Kawasaki JF650 TS (1989-1996)
- Yamaha EX570E Exciter Deluxe (1988-1989)
- Kawasaki JF650 X2 (1986, 1988-1995)
- Kawasaki JS650 650SX (1987-1993)
- Yamaha EX570 Exciter (1987-1990)
- Ski-Doo Stratos (1987)
- Ski-Doo Escapade (1987)
- BMW R100GS (1987-1995)
- Arctic Cat El Tigre (1987)
- Kawasaki JS550 (1982-1988)
- Yamaha TY350 (1985-1986)
- BMW R80 (1985-1987)
- Yamaha XV500 Virago (1983-1984)
- Yamaha XJ750M Mid-Max (1983)
- Kawasaki KZ750K LTD Belt (1983-1984)
- BMW R100 (1983-1984)
- Yamaha XJ750 Maxim (1982-1983)
- BMW R80ST (1982-1984)
- BMW R80RT (1982-1984)
- Yamaha XV750 Virago (1981-1983, 1988-1997)
- Yamaha XJ750R Seca (1981-1983)
- Yamaha XJ650L Turbo Seca (1981-1983)
- Yamaha XT500 (1980-1981)
- Yamaha YT125 Tri-Moto (1980-1985)
- Yamaha SR500 (1980-1981)
- Yamaha XS1100L Mid-Special (1980-1981)
- Kawasaki KZ1300B (1980)
- BMW R80G/S (1980-1986)
- BMW R65 (1980-1987)
- Kawasaki KZ1300 (1979-1982)
- Yamaha XS1100 (1978-1981)
- BMW R100RT (1978-1984)
- Yamaha XS750 (1977-1979)
- BMW R80/7 (1977-1984)
- Yamaha XS360 (1976-1977)
- BMW R100RS (1976-1984)
