NGK SPARK PLUGS DP8EA9 NGK Standard Spark Plug

★★★★★ (0)
NGK Spark Plugs DP8EA9 Spark Plug NGK Standard Spark Plug
NGK SPARK PLUGS
Tap to view 2 more

$3.67

MSRP Pricing shown.

Out of Stock

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

NGK SPARK PLUGS DP8EA9 Part Description

Manufacturer

NGK SPARK PLUGS

Product Description

NGK Standard Spark Plug

Features & Benefits

  • ACTUAL OE or EQUIVALENT DESIGN: OEM quality construction nickel alloy center electrode provides consistent performance
  • RECOMMENDED USAGE: Best for vehicles with OE nickel alloy plugs, not recommended on vehicles with factory precious metal plugs
  • NGK's OE CERAMIC TECHNOLOGY: High grade alumina silicate ceramic creates a stronger insulator for optimal dielectric performance
  • SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
  • COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
  • TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal

NGK SPARK PLUGS DP8EA9 Specifications

Product Attributes

Part NumberDP8EA-9
Stock Number5829
Short Style Spark PlugNo
Service NumberDP8EA-9
Resistance0.0 82
Ground Electrode Tip DesignStandard
Ground ConfigurationJ-Gap
Ground Electrode Core MaterialNickel
Washer(s) IncludedYes
Grade TypeStandard Replacement
Electrical Terminal TypeStud
Center Electrode Core MaterialCopper
Center Electrode Tip MaterialNickel
Pre-Gap Size.036 IN
Ground Electrode Quantity1
Hex Size18mm
Insulator Height1.97 IN
Manufacturer Heat Range8
Seat TypeFlat
Reach0.750 IN
Thread Diameter0.472 IN
Insulator MaterialCeramic
Resistor TypeNo
Skirt Length0.0 IN
Ground Electrode Tip MaterialNickel
SkirtNo
Center Electrode Insulator Tip Projection0.12 IN
Center Electrode DesignStandard
Washer TypeCrush
Center Electrode ProjectionMid Projection
MetallurgyCopper
Thread Type StandardMetric
Pre-Gap Size0.9 MM
Insulator Height50.0 MM
Reach19.0 MM
66480.0 MM
Thread SizeM12 - 1.25
Center Electrode Insulator Tip Projection3.0 MM

Additional Information

Harmonized Tariff Code (HTS)8511100000
Warranty Time UOMMO
Warranty Time2
Country of Origin (Primary)JP
UPC00087295158296
VMRS Code033003005
UNSPSC26101732

NGK SPARK PLUGS DP8EA9 Cross References

BrandPart Number
AUTOLITE4163
Autolite4153
BriskB14YC
CHAMPION809
Champion Spark PlugA6Y, A6YC
DENSO Auto Parts4093, X24EP-U, 4210, X24EP-U9
E3 SPARK PLUGSE336
Honda98069-58911
Kawasaki92070-1066
N/ADP8EA-9
NGK5829
Suzuki09482-00332
TorchD8RTC, D8TC
Yamaha94701-00275, 94703-00275

NGK SPARK PLUGS DP8EA9 Fits Vehicles

  • Kawasaki KL600 (1985-1986)
  • Kawasaki KL650B Tengai (1990)
  • Kawasaki KLF400 Bayou 4x4 (1993-1999)
  • Kawasaki KSF250 Mojave (1987-1999)
  • Kawasaki KVF400 Prairie 2x4 (1999)
  • Kawasaki KVF400 Prairie 4x4 (1997-1999)
  • Kawasaki VN1500A Vulcan 88 (1990)
  • Kawasaki VN1500B Vulcan 88 SE (1990)
  • Suzuki VS1400GL Intruder (1987-1988)
  • Suzuki VS700 Intruder (1985-1987)
  • Yamaha FJ1100 (1984-1985)
  • Yamaha FJ1200 (1986-1993)
  • Yamaha FZ700 (1987)
  • Yamaha FZ750 (1985-1988)
  • Yamaha FZR1000 (1987-1995)
  • Yamaha FZR750R (1987-1988)
  • Yamaha FZX700 Fazer (1986-1987)
  • Yamaha SRX600 (1986)
  • Yamaha TT600 (1986)
  • Yamaha XT600 (1984-1993)
  • Yamaha YFM600FW Grizzly 4x4 (1999-2000)
