(888) 312-8812 Login SignupNGK SPARK PLUGS D7EA NGK Standard Spark Plug
Tap to view 4 more
$3.67
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
NGK SPARK PLUGS D7EA Part Description
Manufacturer
Product Description
NGK Standard Spark Plug
Features & Benefits
- ACTUAL OE or EQUIVALENT DESIGN: OEM quality construction nickel alloy center electrode provides consistent performance
- RECOMMENDED USAGE: Best for vehicles with OE nickel alloy plugs, not recommended on vehicles with factory precious metal plugs
- NGK's OE CERAMIC TECHNOLOGY: High grade alumina silicate ceramic creates a stronger insulator for optimal dielectric performance
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
- TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
NGK SPARK PLUGS D7EA Specifications
Product Attributes
| Stock Number | 7912 |
| Part Number | D7EA |
| Short Style Spark Plug | No |
| Service Number | D7EA |
| Resistance | 0.0 82 |
| Ground Electrode Tip Design | Standard |
| Ground Configuration | J-Gap |
| Ground Electrode Core Material | Nickel |
| Washer(s) Included | Yes |
| Grade Type | Standard Replacement |
| Electrical Terminal Type | Stud |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Nickel |
| Pre-Gap Size | .028 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 18mm |
| Insulator Height | 1.97 IN |
| Manufacturer Heat Range | 7 |
| Seat Type | Flat |
| Reach | 0.750 IN |
| Thread Diameter | 0.472 IN |
| Insulator Material | Ceramic |
| Resistor Type | No |
| Skirt Length | 0.0 IN |
| Ground Electrode Tip Material | Nickel |
| Skirt | No |
| Center Electrode Insulator Tip Projection | 0.06 IN |
| Center Electrode Design | Standard |
| Washer Type | Crush |
| Center Electrode Projection | Non-Projected |
| Metallurgy | Copper |
| Thread Type Standard | Metric |
| Pre-Gap Size | 0.7 MM |
| Insulator Height | 50.0 MM |
| Reach | 19.0 MM |
| 6648 | 0.0 MM |
| Thread Size | M12 - 1.25 |
| Center Electrode Insulator Tip Projection | 1.6 MM |
Additional Information
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | JP |
| Harmonized Tariff Code (HTS) | 8511100000 |
| UPC | 00087295179123 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
NGK SPARK PLUGS D7EA Cross References
| Brand | Part Number |
|---|---|
| ACDelco | S123XL |
| AUTOLITE | AR4133, 4163, 4132 |
| Autolite | 4164, 4164DP |
| Beck/Arnley | 1765230 |
| CHAMPION | 810 |
| Champion Spark Plug | P-A5HC, R8, P-A7HC, A10, A8 |
| DENSO Auto Parts | 4090, X22ES-U |
| E3 SPARK PLUGS | E336 |
| Honda | 98069-57717 |
| Kawasaki | 92070-1013 |
| MOOG | 810 |
| N/A | D7EA |
| NGK | 7912 |
| SYM | 98069-57717-02 |
| Suzuki | 09482-00182 |
| Torch | D7CA, D7, D7RC |
| Yamaha | 94701-00189, 94703-00189 |
NGK SPARK PLUGS D7EA Fits Vehicles
- BMW K100LT (1987-1992)
- BMW K100LT ABS (1989-1992)
- BMW K100RS (1984-1988)
- BMW K100RS ABS (1988-1989)
- BMW K75 (1990-1994)
- BMW K75C (1986-1988)
- BMW K75RT (1990-1992)
- BMW K75RT ABS (1991-1995)
- BMW K75S (1987-1992)
- BMW K75S ABS (1991-1995)
- BMW K75T (1986-1987)
- Honda CB550F Super Sport (1975-1977)
- Honda CB550K (1974-1978)
- Honda TL250 (1975-1976)
- Kawasaki KLT110 (1984-1985)
- Suzuki ALT125 (1983-1986)
- Suzuki ALT185 (1985)
- Suzuki LT-F230 (1987)
- Suzuki LT-F250 QuadRunner (1988-2001)
- Suzuki LT-F300F KingQuad 4x4 (1999-2002)
- Suzuki LT125 (1985-1987)
- Suzuki LT160E (1989)
- Suzuki LT185 (1984-1987)
- Suzuki LT230E QuadRunner (1987-1993)
- Suzuki LT230GE (1985-1986)
- Suzuki LT230S QuadSport (1985-1988)
- Yamaha SR185 (1981-1982)
- Yamaha TT600 (1983-1984)
- Yamaha XT550 (1982-1983)
- Yamaha YFM200 Moto-4 (1985-1989)
- Yamaha YFM225 Moto-4 (1986-1988)
- Yamaha YTM200 Tri-Moto (1983-1985)
