NGK SPARK PLUGS DPR7EA9 Part Description
Manufacturer
Product Description
NGK Standard Spark Plug
Features & Benefits
- ACTUAL OE or EQUIVALENT DESIGN: OEM quality construction nickel alloy center electrode provides consistent performance
- RECOMMENDED USAGE: Best for vehicles with OE nickel alloy plugs, not recommended on vehicles with factory precious metal plugs
- NGK's OE CERAMIC TECHNOLOGY: High grade alumina silicate ceramic creates a stronger insulator for optimal dielectric performance
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
- TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
NGK SPARK PLUGS DPR7EA9 Specifications
Product Attributes
| Stock Number | 5129 |
| Part Number | DPR7EA-9 |
| Short Style Spark Plug | No |
| Service Number | DPR7EA-9 |
| Resistance | 5000.0 82 |
| Ground Electrode Tip Design | Standard |
| Ground Configuration | J-Gap |
| Ground Electrode Core Material | Nickel |
| Washer(s) Included | Yes |
| Grade Type | Standard Replacement |
| Electrical Terminal Type | Stud |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Nickel |
| Pre-Gap Size | .036 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 18mm |
| Insulator Height | 1.97 IN |
| Manufacturer Heat Range | 7 |
| Seat Type | Flat |
| Reach | 0.750 IN |
| Thread Diameter | 0.472 IN |
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| Skirt Length | 0.0 IN |
| Ground Electrode Tip Material | Nickel |
| Skirt | No |
| Center Electrode Insulator Tip Projection | 0.12 IN |
| Center Electrode Design | Standard |
| Washer Type | Crush |
| Center Electrode Projection | Mid Projection |
| Metallurgy | Copper |
| Thread Type Standard | Metric |
| Pre-Gap Size | 0.9 MM |
| Insulator Height | 50.0 MM |
| Reach | 19.0 MM |
| 6648 | 0.0 MM |
| Thread Size | M12 - 1.25 |
| Center Electrode Insulator Tip Projection | 3.0 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8511100000 |
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | JP |
| UPC | 00087295151297 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
NGK SPARK PLUGS DPR7EA9 Cross References
| Brand | Part Number |
|---|---|
| AUTOLITE | 4164 |
| Arctic Cat | 0217-730 |
| Bosch | X5DC, XR5DC, XR7LDC |
| CHAMPION | 810, 810ECO |
| Champion Spark Plug | 449, RA8YC, RA8Y, RA8HC, 810, RAX96YC |
| DENSO Auto Parts | 4086, X22EPR-U9 |
| E3 SPARK PLUGS | E336 |
| Honda | 98069-57916 |
| John Deere | TY26722 |
| Kawasaki | 92070-1125 |
| MOOG | 810 |
| N/A | DPR7EA-9 |
| NGK | 5129 |
| Peugeot | 756756 |
| SYM | 98069-57916-00 |
| Suzuki | 09482-00354 |
| Yamaha | 94701-00262, 94703-00262 |
NGK SPARK PLUGS DPR7EA9 Fits Vehicles
- Honda VT750C2BS Shadow Phantom ABS (2024)
- KYMCO MXU300R (2022)
- KYMCO Mongoose 270i (2023-2024)
- KYMCO MXU270i EURO (2020-2021, 2023)
- KYMCO Mongoose 270 EURO (2020-2021)
- KYMCO MXU270 (2016-2018, 2020-2021)
- KYMCO Mongoose 270 (2016-2018, 2020-2021)
- Textron Alterra 300 (2018)
- Yamaha XV19B Star Eluder (2018)
- Yamaha Star Venture (2018)
- Arctic Cat Alterra 300 (2017, 2020-2024)
- CFMOTO CF500A (2010)
- CFMOTO CF600-5 (Rancher 600) (2011)
- CFMOTO X5 (Terralander 500) SWB (2011-2012)
- CFMOTO X6 (Terralander 625) SWB (2012)
- CFMOTO X5 (Terralander 500) LWB (2011-2012)
- CFMOTO X6 (Terralander 625) LWB (2011-2012)
- CFMOTO CFORCE 500 (2013-2015)
- CFMOTO UFORCE 600 (2013)
- CFMOTO CFORCE 600 (2013-2014)
- CFMOTO CF500-3 (Rancher 500) (2011-2012)
- CFMOTO CF500 (2007-2010)
- CFMOTO Z6 (Terracross 600) (2011-2012)
- CFMOTO ZFORCE 600 (2013-2015)
- CFMOTO ZFORCE 600 EX (2013-2015)
- Triumph Rocket III Roadster ABS (2015-2016)
- Triumph Rocket III Touring ABS (2015-2016)
- Triumph Rocket III Touring (2014, 2016-2017)
- Suzuki C50 Boulevard B.O.S.S. (2014)
- Honda VT750C2 Shadow Spirit ABS (2013)
- Honda VT750CA Shadow Aero ABS (2013-2016, 2018-2020, 2022, 2024)
- Suzuki C50T Boulevard Classic (2012)
- KYMCO Xciting 250 (2006-2011)
- KYMCO People S 250 (2006-2011)
- KYMCO People 250 (2004-2007)
- KYMCO Grandvista 250 (2004-2011)
- KYMCO Bet & Win 250 (2002-2004)
- KYMCO Bet & Win 150 (2004-2007)
- Honda VT750C Shadow Aero (2011-2016, 2018-2020, 2022-2024)
- Honda VT750C2 Shadow Spirit (2012-2014)
- Honda NSS 250 Jazz (2001-2004)
- Honda XR650L (2012, 2017-2020)
- Honda CRF230F (2012-2017, 2019)
- Kawasaki KVF300 Brute Force (2012-2018, 2020-2024)
- Triumph Rocket III Roadster (2011-2014, 2016-2019)
- Honda TRX250X (2009, 2011-2014, 2016-2020)
- Honda VT750C2B Shadow Phantom (2010-2020, 2022-2024)
- Honda VT750RS Shadow RS (2010-2013)
- Arctic Cat 300 2x4 Auto (2010)
- Arctic Cat 300 (2010-2016)
- Suzuki M50 Boulevard SE (2009)
- Suzuki C50 Boulevard SE (2009, 2013)
- Arctic Cat DVX 300 (2009-2015)
- Yamaha XV1700ATS Road Star Silverado S (2008-2014)
- Yamaha XV1700AS Road Star S (2008-2014)
- KYMCO Maxxer 300 (2008)
- KYMCO Maxxer 250 (2008)
- Triumph Rocket III Classic Tourer (2007-2011)
- Suzuki M50 Boulevard Limited (2007)
- Triumph Rocket III Classic (2006-2009)
- Suzuki M50 Boulevard (2006-2009)
- KYMCO Mongoose 300 (2006-2011, 2013, 2015)
- Arctic Cat DVX 250 (2006-2008)
- Arctic Cat 250 2x4 (2006-2009)
- Yamaha XV1700PCM Road Star Midnight Warrior (2005-2009)
- Yamaha XV1700AT Road Star Silverado (2005-2010)
- Suzuki M50B Boulevard (2005-2006)
- Suzuki C50T Boulevard (2005-2009, 2011-2019)
- Suzuki C90 Boulevard (2005-2009)
- Suzuki C50B Boulevard (2005-2008)
- Suzuki C90B Boulevard (2005-2008)
- Suzuki C50 Boulevard (2005-2009, 2013, 2015-2019)
- KYMCO MXU300 (2005-2011, 2013, 2015)
- Honda VT600CD Shadow VLX Deluxe (2005)
- Honda PS250 Big Ruckus (2005-2006)
- Yamaha XV1700ATM Road Star Midnight Silverado (2004-2007)
- Yamaha XV1700A Road Star (2004-2009)
- Yamaha XV1700AM Road Star Midnight (2004-2007)
- KYMCO MXU250 (2004-2009)
- KYMCO Mongoose 250 (2004-2009)
- Honda TRX400FGA FourTrax Rancher AT GPScape (2004-2007)
- Honda NSS250S Reflex Sport (2004-2007)
- Honda TRX400FA FourTrax Rancher AT (2004-2007)
- Honda NSS250AS Reflex Sport ABS (2004-2007)
- Suzuki LT160 (2003)
- Honda CRF150F (2003-2005)
- Yamaha XV1700PC Road Star Warrior (2002-2009)
- Yamaha XVS650AT V Star Silverado (2002-2010)
- Honda TRX450FE FourTrax Foreman ES (2002-2004)
- Honda TRX250TE FourTrax Recon ES (2002-2009, 2011-2014, 2016-2020)
- Honda TRX450FM FourTrax Foreman S (2002-2004)
- Honda TRX250TM FourTrax Recon (2002-2009, 2011-2014, 2016-2020)
- Suzuki VL800 Intruder Volusia (2001-2004)
- Honda TRX250EX Sportrax (2001-2008)
- Honda NSS250A Reflex ABS (2001-2007)
- Honda NSS250 Reflex (2001-2007)
- Yamaha XV1600AS Road Star Midnight (2000-2003)
- Honda TRX350TM FourTrax Rancher (2000-2006)
- Honda VT1100C2 Shadow Sabre (2000-2007)
- Honda TRX350TE FourTrax Rancher ES (2000-2006)
- Honda TRX350FM FourTrax Rancher 4X4 (2000-2006)
- Honda TRX350FE FourTrax Rancher 4x4 ES (2000-2006)
- Yamaha XVZ1300AL Royal Star Boulevard (1999-2001)
- Yamaha XV1600AT Road Star Silverado (1999-2003)
- Yamaha XV1600A Road Star (1999-2003)
- Honda GL1500CF Valkyrie Interstate (1999-2001)
- Yamaha XVS650A V Star Classic (1998-2010)
- Yamaha XVS650 V Star Custom (1998-2011, 2013-2016)
- Suzuki VL1500 Intruder (1998-2004)
- Suzuki LT-F160 QuadRunner (1998-2001)
- Honda VT1100T Shadow ACE Tour (1998-2001)
- Honda VT1100C3 Shadow Aero (1998-2002)
- Honda VT1100C2 Shadow ACE (1998-1999)
- Yamaha XVZ1300CT Royal Star Tour Deluxe (1997-2001)
- Honda VT1100C Shadow Spirit (1997-2007)
- Honda GL1500C/CD Valkyrie (1997-2003)
- Honda GL1500CT Valkyrie Tour (1997-2000)
- Yamaha XVZ1300AT Royal Star Tour Classic (1996-2000)
- Yamaha XVZ1300A Royal Star (1996-1998)
- Kawasaki VN1500E Vulcan 1500 Classic (1996-1998)
- Kawasaki VN1500C Vulcan L (1996-1997)
- Kawasaki VN1500A Vulcan 1500 (1996-1999)
- Honda TRX400FW Foreman 4x4 (1995-2003)
- Honda GL1500I Gold Wing Interstate (1992-1996)
- Honda GL1500A Gold Wing Aspencade (1991-2000)
- Honda GL1500SE Gold Wing Special Edition (1990-2000)
- Honda PC800 Pacific Coast (1989-1990, 1994-1998)
- Honda VT800C Shadow (1988)
- Honda GL1500 Gold Wing (1988-1990)
- Yamaha XC200 Riva (1987-1991)
- Yamaha XC200Z Riva (1987-1989)
- Honda VT1100C Shadow (1987-1990, 1992-1996)
- Honda CH150 Elite (1987)
- Honda VT700C Shadow (1986-1987)
- Honda CH150D Elite Deluxe (1985-1986)
- Honda CH125 Elite (1984)
