NGK SPARK PLUGS D9EA Part Description
Manufacturer
Product Description
NGK Standard Spark Plug
Features & Benefits
- ACTUAL OE or EQUIVALENT DESIGN: OEM quality construction nickel alloy center electrode provides consistent performance
- RECOMMENDED USAGE: Best for vehicles with OE nickel alloy plugs, not recommended on vehicles with factory precious metal plugs
- NGK's OE CERAMIC TECHNOLOGY: High grade alumina silicate ceramic creates a stronger insulator for optimal dielectric performance
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
- TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
NGK SPARK PLUGS D9EA Specifications
Product Attributes
| Stock Number | 2420 |
| Part Number | D9EA |
| Short Style Spark Plug | No |
| Service Number | D9EA |
| Resistance | 0.0 82 |
| Ground Electrode Tip Design | Standard |
| Ground Configuration | J-Gap |
| Ground Electrode Core Material | Nickel |
| Washer(s) Included | Yes |
| Grade Type | Regular |
| Electrical Terminal Type | Stud |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Nickel |
| Pre-Gap Size | .028 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 18mm |
| Insulator Height | 1.97 IN |
| Manufacturer Heat Range | 9 |
| Seat Type | Flat |
| Reach | 0.750 IN |
| Thread Diameter | 0.472 IN |
| Insulator Material | Ceramic |
| Resistor Type | No |
| Skirt Length | 0.0 IN |
| Ground Electrode Tip Material | Nickel |
| Skirt | No |
| Center Electrode Insulator Tip Projection | 0.06 IN |
| Center Electrode Design | Standard |
| Washer Type | Crush |
| Center Electrode Projection | Non-Projected |
Additional Information
| Harmonized Tariff Code (HTS) | 8511100000 |
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | JP |
| UPC | 00087295124208 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
NGK SPARK PLUGS D9EA Part Interchanges
| Brand | Part Number |
|---|---|
| NGK | 2420 |
| Suzuki | 09482-00184 |
| Honda | 98069-59717 |
| Yamaha | 94701-00266, 94703-00266 |
| DENSO Auto Parts | 4114, X27ES-U |
| Kawasaki | 92070-1034 |
| Champion Spark Plug | 662, A61, A59C |
NGK SPARK PLUGS D9EA Fits Vehicles
- Kawasaki KZ305B CSR Belt (1982)
- Kawasaki ZX600 Ninja ZX-6R (1995-1997)
- Kawasaki EX500 Ninja 500 (1994-1996)
- Kawasaki ZR750C Zephyr (1991-1992)
- Kawasaki ZX600 Ninja ZX-6 (1990-1997)
- Kawasaki EN500 Vulcan 500 (1990-1996)
- Kawasaki KZ305B LTD (1987-1988)
- Suzuki GSX-R750 (1986-1987)
- Kawasaki ZL600 Eliminator (1986-1987)
- Kawasaki ZX600 Ninja 600R (1985-1997)
- Kawasaki EN450A 454 LTD (1985-1986, 1988-1990)
- Suzuki XN85 Turbo (1983)
- Suzuki GS550L (1983-1986)
- Suzuki GS550E (1983-1986)
- Suzuki GS550ES (1983-1986)
- Suzuki GS300L (1982-1983)
- Kawasaki KZ305 CSR (1981-1982)
- Honda CB900F Super Sport (1981)
- Suzuki GS250T (1980-1981)
- Honda CB900C Custom (1980-1981)
- Yamaha TX500 (1973-1974)
