DAYCO part description

Product Description

PREMIUM OEM REPL BALANCER, POWERBOND

Product Attributes

Overall Outside Diameter 7.993 in
Overall Outside Diameter 203.00 mm
Crank Bore 1.601 in
Crank Bore 40.65 mm
Overall Width 3.150 in
Overall Width 80.00 mm
Nose Outside Diameter 2.334 in
Nose Outside Diameter 59.27 mm
Ring Width 1.319 in
Ring Width 33.48 mm
Bolt Hole Quantity 4
Crank Trigger/Exciter Plate No
Woodruff Key Included No
Hardware Included No
Counterweight Balance Hub weighted
Timing Marks Yes
Installation Instructions Included No
Number of Integrated Pulleys 0
Outer Ring Material Cast Iron

Additional Information

Country of Origin (Primary) AU
Harmonized Tariff Code (Schedule B) 8483509080
UPC 09317010000298

Part Interchanges

Fits Vehicles

  • GMC C3500HD (1992)
  • Chevrolet C3500HD (1992)
  • GMC V3500 (1987-1991)
  • GMC V2500 Suburban (1987-1991)
  • GMC V2500 (1987)
  • GMC V1500 Suburban (1987-1991)
  • GMC V1500 (1987)
  • GMC R3500 (1987-1991)
  • GMC R2500 Suburban (1987-1991)
  • GMC R2500 (1987-1989)
  • GMC R1500 Suburban (1987-1991)
  • GMC R1500 (1987)
  • GMC P3500 (1982-1993)
  • GMC P2500 (1982-1989)
  • GMC K3500 (1982-1986, 1988-1993)
  • GMC K2500 Suburban (1982-1986)
  • GMC K2500 (1982-1986, 1988-1993)
  • GMC K1500 Suburban (1982-1986)
  • GMC K1500 (1982-1986, 1988-1993)
  • GMC Jimmy (1982-1991)
  • GMC G3500 (1983-1993)
  • GMC G2500 (1983-1993)
  • GMC C3500 (1982-1986, 1988-1993)
  • GMC C2500 Suburban (1982-1986)
  • GMC C2500 (1982-1986, 1988-1993)
  • GMC C1500 Suburban (1982-1986)
  • GMC C1500 (1982-1986, 1988-1993)
  • Chevrolet V3500 (1989-1991)
  • Chevrolet V30 (1987-1988)
  • Chevrolet V2500 Suburban (1989-1991)
  • Chevrolet V20 Suburban (1987-1988)
  • Chevrolet V20 (1987)
  • Chevrolet V1500 Suburban (1989-1991)
  • Chevrolet V10 Suburban (1987-1988)
  • Chevrolet V10 (1987)
  • Chevrolet R3500 (1989-1991)
  • Chevrolet R30 (1987-1988)
  • Chevrolet R2500 Suburban (1989-1991)
  • Chevrolet R2500 (1989)
  • Chevrolet R20 Suburban (1987-1988)
  • Chevrolet R20 (1987-1988)
  • Chevrolet R1500 Suburban (1989-1991)
  • Chevrolet R10 Suburban (1987-1988)
  • Chevrolet R10 (1987)
  • Chevrolet P30 (1982-1993)
  • Chevrolet P20 (1982-1989)
  • Chevrolet K3500 (1988-1993)
  • Chevrolet K30 (1982-1986)
  • Chevrolet K2500 (1988-1993)
  • Chevrolet K20 Suburban (1982-1986)
  • Chevrolet K20 (1982-1986)
  • Chevrolet K1500 (1988-1993)
  • Chevrolet K10 Suburban (1982-1986)
  • Chevrolet K10 (1982-1986)
  • Chevrolet G30 (1983-1993)
  • Chevrolet G20 (1983-1993)
  • Chevrolet C3500 (1988-1993)
  • Chevrolet C30 (1982-1986)
  • Chevrolet C2500 (1988-1993)
  • Chevrolet C20 Suburban (1982-1986)
  • Chevrolet C20 (1982-1986)
  • Chevrolet C1500 (1988-1993)
  • Chevrolet C10 Suburban (1982-1986)
  • Chevrolet C10 (1982-1986)
  • Chevrolet K5 Blazer (1982-1986)
  • Chevrolet Blazer (1987-1991)
