Sealed Power WH868CP - Sealed Power WH868CP Engine Piston
- Part Number
- WH868CP
- Manufacturer
- SEALED POWER
- Description
-
Sealed Power WH868CP Engine Piston
details
$5949
MSRP: $97.78
Save: $38.29
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
SEALED POWER part description
Product Description
Engine Piston
Features & Benefits
- Helps improve cylinder sealing for less blow-by
- Retains standard ring gaps in top groove
- DUROSHIELD(R) skirt-coated piston
- DUROSHIELD® skirt-coated piston
- Moly-graphite coating extends engine life
- Reduces friction for higher fuel economy
- Prevents damage from inadequate lubrication on start-up
Product Attributes
| Oversized | No |
| Top Compression Ring Thickness | 1.50 MM |
| Second Compression Ring Thickness | 1.50 MM |
| Oil Ring Thickness | 3.00 MM |
| Piston Pin Outside Diameter | 0.945 IN |
| Piston Head Type | Flat |
| Assembly Lubricant Included | No |
| Cylinder Bore Diameter | 3.897 IN |
| Piston Material | Hypereutectic |
| 9607 | 1.328 IN |
| Head Illustration | 23 |
| Head Type | Flat; DUROSHIELD~ skirt coated piston |
| Lock Ring | N/R |
| Minimum Clearance | 0.0015 |
| Part Description | Engine Piston |
| Pin Offset (Inch) | 0.03 |
| Pin Offset (MM) | 0.762 |
| Pin Type | P |
| Pin Weight Gram | 151 |
| Weight W Pin Gram | 598 |
| Weight w/o Pin Gram | 447 |
| Grade Type | Premium |
Additional Information
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8409910010 |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Harmonized Tariff Code (HTS) | 8409915085 |
| UPC | 00614046726444 |
Part Interchanges
Fits Vehicles
- Pontiac Firebird (1998-2002)
- Pontiac GTO (2004)
- Chevrolet Corvette (1997-2004)
- Chevrolet Camaro (1998-2002)
