(888) 312-8812 Login SignupSEALED POWER H554CP60 Sealed Power H554CP 60 Engine Piston
$23094
Package Price for 6 Units
@ $38.49 per unit
Limited availability at this price!
In Stock
Get it by Friday, Aug 14
SEALED POWER H554CP60 Part Description
Manufacturer
Product Description
Engine Piston
Features & Benefits
- Helps improve cylinder sealing for less blow-by
- Retains standard ring gaps in top groove
- DUROSHIELD(R) skirt-coated piston
- DUROSHIELD® skirt-coated piston
- Moly-graphite coating extends engine life
- Reduces friction for higher fuel economy
- Prevents damage from inadequate lubrication on start-up
SEALED POWER H554CP60 Specifications
Product Attributes
| Oversized | Yes |
| Oversized Amount | 0.060 IN |
| Top Compression Ring Thickness | 0.0781 IN |
| Second Compression Ring Thickness | 0.0781 IN |
| Oil Ring Thickness | 0.1875 IN |
| Piston Pin Outside Diameter | 0.9751 IN |
| Piston Head Type | Recessed |
| Assembly Lubricant Included | No |
| Cylinder Bore Diameter | 4.0000 IN |
| Piston Material | Hypereutectic |
| Compression Height | 1.767 IN |
| Head Illustration | 28 |
| Head Type | Recessed Head .300 deep x 3.210 dia. - 7.8:1 C.R.; DUROSHIELD~ skirt coated piston |
| Minimum Clearance | See Piston Fitting Information on carton label |
| Part Description | Engine Piston |
| Pin Offset (Inch) | 0.062 |
| Pin Offset (MM) | 1.575 |
| Pin Type | P |
| Grade Type | Premium |
| Piston Pin Outside Diameter | 24.768 MM |
| Grade Type | Premium |
Additional Information
| Country of Origin (Primary) | IN |
| Canadian Harmonizing Tariff Code | 8409910010 |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Harmonized Tariff Code (HTS) | 8409915085 |
| UPC | 00614046686809 |
| VMRS Code | 045006005 |
SEALED POWER H554CP60 Cross References
| Brand | Part Number |
|---|---|
| Badger | P719A-060, P719A060 |
| Clevite | 9-3136.060, 93136060 |
| Dana Commercial Vehicle Service Parts | 224-2704.060, 2242704060 |
| Ertel | 1002AP60, 1002P60 |
| N/A | 3136.060 |
| Silvolite | 3136060 |
