CENTRIC part description

Make Ford, Mercury
Model Colony Park, Country Sedan, Country Squire, Custom, Custom 500, Galaxie 500, Lobo, LTD, Marauder, Marquis, Monterey, Ranch Wagon
Year 1969

Product Description

C-Tek Standard Brake Drum

Application Summary

Ford Country Sedan 1972-1969, Country Squire 1972-1971, Custom 1972-1969, Custom 500 1972-1969, Galaxie 500 1972-1969, Lobo 2008-2005, LTD 1972-1969, Ranch Wagon 1972-1969, Mercury Colony Park 1971-1969, Marauder 1970-1969, Marquis 1971-1969, Monterey 1971-1969

Features & Benefits

  • Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket

C-Tek; Centric; Standard brake rotor; standard brake drum; Centric standard Drums; Centric c-tek standard brake drum

Product Attributes

Maximum Brake Diameter (Discard) 281.700 MM
Bolt Hole Quantity 5
Outside Diameter 325.120 MM
Outer Cooling Fins No
Mounting Hole Diameter 16.000 MM
Nominal Drum Diameter 279.400 MM
Bolt Circle Diameter [cntrc] In 4.500
Bolt Circle Diameter [cntrc] Mm 114.300
Friction Surface Width [cntrc] In 3.410
Friction Surface Width [cntrc] Mm 86.614
Height [cntrc] In 3.760
Height [cntrc] Mm 95.504
Hub Hole / Register [cntrc] In 2.780
Hub Hole / Register [cntrc] Mm 70.612
Misc Holes [cntrc] 5
Mounting Type [cntrc] Floating
Weight [cntrc] Kgs 9.636
Weight [cntrc] Lbs 21.200

Additional Information

Country of Origin (Primary) CN
Harmonized Tariff Code (Schedule B) 8708300050
Harmonized Tariff Code (HTS) 8708305030
NAFTA Preference Criterion Code B
UPC 00805890977667
CENTRIC 123.61033 Cross Reference

We have 2 alternatives for the 123.61033 by CENTRIC:

Fits Vehicles

  • Ford Lobo (2005-2008)
  • Ford Custom (1969-1972)
  • Mercury Monterey (1969-1971)
  • Mercury Marquis (1969-1971)
  • Mercury Marauder (1969-1970)
  • Mercury Colony Park (1969-1971)
  • Ford Ranch Wagon (1969-1972)
  • Ford LTD (1969-1972)
  • Ford Galaxie 500 (1969-1972)
  • Ford Custom 500 (1969-1972)
  • Ford Country Squire (1971-1972)
  • Ford Country Sedan (1969-1972)

Formed in 2017, Centric® brings two of the industry’s leading undercar parts manufacturers, AP Emissions Technologies and Centric Brakes, under one brand. The merger combines more than 90 years’ worth of experience in aftermarket performance exhaust solutions with market leadership in brakes and chassis systems, resulting in an extensive portfolio of undercar components made available to distribution partners worldwide. From brake discs to catalytic converters, APC-Centric products make use of high-quality materials precision engineering to provide reliable performance at a reasonable cost to the customer. Also, as part of the larger APC Automotive Technologies group, APC-Centric has the competitive advantage of vertically-integrated supply chain and access to a global network of R&D, testing, and manufacturing facilities and customer support channels.
