WEBB part description

DRUM INFORMATION
Drum Part Number: 56864B
Weight: 104
Brake Shoe Width: 7
Brake Face Thickness: 0.48
Drum Type:

Mount: Outboard
Brake Surface Diameter: 16.50
Overall Depth: 10.52
Brake Surface Flat: 7.54
Pilot Diameter: 8.78
Bolt Circle Diameter: 11.25
Bolt Hole (Number): 10
Bolt Hole Size: 1.08
Maximum Wear Diameter: 16.62
Notes: Use 66884B for heavy duty applications.

WEBB 56864F Cross Reference

We have 3 alternatives for the 56864F by WEBB:

In business since 1946, Webb® has been a trusted brand for high-quality brake and wheel hub components in the heavy duty transportation industry. The company maintains an extensive catalog of OEM and aftermarket brake drums, brake rotors and calipers, and wheel hubs for Class 6, 7, and 8 trucks and heavy duty trailers. Each Webb product is made of premium materials and engineered for reduced weight without compromising structural strength or balance. All parts are also manufactured using the latest innovations, including advanced wear indicators and cool running vent technology to help minimize wear and make maintenance and repairs easier. Combined with a first-class customer service and after-sales support, customers can count on Webb products to keep their trucks running safely and smoothly for years to come.
