(888) 312-8812 Login SignupDELPHI ES20036 Oxygen Sensor
$9849
Limited availability at this price!
5 Day Lead Time
Get it by Thursday, Feb 12
DELPHI ES20036 Part Description
Manufacturer
Product Description
Oxygen Sensor
Features & Benefits
- Delphi planar technology covers older, conical design sensors
- Smart design consolidates SKUs without using long wires
- Patented protective sensor coating helps prevent contamination
- Validated for all fuel types, including ethanol blends like E85
- OE tested to 150,000 miles, plus 2,000 hours severe thermal testing
- Delphi is a global OE manufacturer for oxygen sensor and all oxygen sensors are built to Delphi's OE standards
DELPHI ES20036 Specifications
Product Attributes
| Package Contents | Oxygen Sensor, Instruction Sheet |
| Position(s) | Front, Rear. For the position specific to your vehicle, refer to the Applications. |
| Wiring Harness Length | 20.5 IN |
| Wiring Harness Length | 520.0 MM |
| Sensor Type | Narrow-Band |
| Terminal Type | Blade |
| Universal Or Specific Fit | Specific |
| Band Type | Narrow |
| Wire Quantity | 4 |
| Grade Type | Standard Replacement |
| Connector Shape | Square |
| Terminal Quantity | 4 |
| Connector Gender | Female |
| Terminal Gender | Male |
| Thread Diameter | 0.7 IN |
| Wrench Size | 22mm |
| Thread Size | M18 - 1.5 |
| Overall Length | 21.7 IN |
| Overall Length | 550.0 MM |
| Mounting Type | Threaded |
| Thread Diameter | 18.0 MM |
| Wire Gauge Measurement | 20.0 GU |
| Thread Type Standard | Metric |
| Heated | Yes |
Additional Information
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9027100000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 9027102000 |
| UPC | 00689604148297 |
| VMRS Code | 045021011 |
| UNSPSC | 41111924 |
DELPHI ES20036 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 2131356, 2131359, 2131360, 2131431, 2131466 |
| BorgWarner | OS2079, OS600, OS601 |
| Bosch | 13293, 13447, 15711 |
| DENSO | 234-4055, 234-4056, 234-4507 |
| DENSO Auto Parts | 234-4055, 234-4056, 234-4507 |
| Kem | 138-263, 138-593 |
| N/A | 2344055, 2344056, 138263, 138593, 8946519205, 8946519206, 8946535070, 8946535080, 8946535090, 8946535100, 8946535140, 8946539255, 8946539256, 8946539265, 8946539275, 8946539295, 8946539296, 8946539335, 8946539336, 8946539355, 8946539365, 250-24508 |
| NTK | 24059, 24111, 24539 |
| Oextra | REA1061 |
| SPECTRA PREMIUM | OS5125, OS5284 |
| Standard Motor Products | SG263, SG657, SG80, SG18 |
| Toyota | 89465-19205, 89465-19206, 89465-35070, 89465-35080, 89465-35090, 89465-35100, 89465-35140, 89465-39255, 89465-39256, 89465-39265, 89465-39275, 89465-39295, 89465-39296, 89465-39335, 89465-39336, 89465-39355, 89465-39365 |
| Walker Products | 25024056 |
| Wells | SU4816, SU4893, SU4894, SU4896, SU4900, SU4901 |
DELPHI ES20036 Fits Vehicles
- Toyota Pickup (1989-1991)
- Toyota MR2 (1988-1989)
- Toyota 4Runner (1990-1991)
