(888) 312-8812 Login SignupDELPHI HP10089 Fuel Pump Hanger Assembly
MSRP: $319.80
$21299
Save $106.81
Limited availability at this price!
In Stock
Get it by Thursday, Jul 9
DELPHI HP10089 Part Description
Manufacturer
Product Description
Fuel Pump Hanger Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Delphi pumps are designed to operate under extreme temperatures with quick engine starts
- Metal tubes in Delphi hangers are routed so as to not contact the tank at any point eliminating noise and vibration during vehicle operation
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Restores fast pressure performance and system integrity, translating to better pumping through less energy
- Lower failure rates due to its innovative design and durability
- Part is validated, tested and matched to the right vehicle application
- Lower amperage draws less load on vehicle's electrical system
- Always be sure to check and clean fuel tank to avoid unnecessary returns
DELPHI HP10089 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Package Contents | Fuel Pump Hanger Assembly w/Float Arm, (2) Retainer Clips, Instruction Sheet |
| Fuel Level Sender Assembly Included | Yes |
| System Pressure | 44 psi |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 12.0 2H |
| Fuel Type | Gas |
| Maximum Pressure | 73.0 PS |
| Terminal Type | Pin |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 2 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 16.0 82 |
| Resistance Ohms Full | 160.0 82 |
| Internal Or External Strainer | External |
| Pump Type | Electric |
| Average Current Draw | 6.0 68 |
| Average Flow Rating | 29.0 GPH |
| Material | Metal |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Shape | Round |
| Lock Ring Included | No |
| Connector Gender | Female |
| Inlet Quantity | 1 |
| Fuel Pump Included | Yes |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 44 PS |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | No |
| Universal Or Specific Fit | Specific |
Additional Information
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Country of Origin (Primary) | MX |
| UPC | 00689604194485 |
| VMRS Code | 044003257 |
| UNSPSC | 40151532 |
DELPHI HP10089 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | EP2017H |
| AUTOBEST | F1248A, F1232A |
| Airtex | E2237S, E2471, E2221S |
| AutoZone | DHP10089 |
| Bosch | 67135, 66118, 67125, 67230, 67232, 67240, 69131 |
| CARTER FUEL PUMPS | P74853S |
| Carquest | HS2420427 |
| Carter | P74853S, P74183, P74184, P74204, P74849S |
| DENSO Auto Parts | 951-0008, 951-0016, 953-4083, 953-4100, 953-4101, 953-4125, 953-4127 |
| EVO Driveline | AFS0109P, RE0109P, RE0315S, AFS0022P, RE0175S, AFS0243S, AFS0315S, AFS0887P, RE0243S, RE0887P |
| Ford | F75U 9H307-AC, F75Z 9H307-AC, F75Z 9H307-AD, F85U 9H307-AB, F85U 9H307-BB, F85Z 9H307-AB, F85Z 9H307-BB, XL3U 9H307-AB, XL3U 9H307-BB, XL3U 9H307-DB, XL3U 9H307-EB, XL3Z 9H307-AB, XL3Z 9H307-BB, XL3Z 9H307-DB, XL3Z 9H307-EB |
| GMB | 525-2020 |
| MasterPro Fuel Pumps | MPA30034 |
| Motorcraft | PFS-104, PFS-105, PFS-107, PFS-108, PFS-52, PFS-75, PFS-76 |
| N/A | 9510008, 9534125, 9534127, XL3U9H307AB, XL3U9H307BB, XL3U9H307DB, XL3U9H307EB, XL3Z9H307AB, XL3Z9H307EB, PFS104, PFS105, PFS107, PFS108, 9510016, 9534083, 9534100, 9534101, E2158, E2211S, E2216S, E2380, F75U9H307AC, F75Z9H307AC, F75Z9H307AD, F85U9H307AB, F85U9H307BB, F85Z9H307AB, F85Z9H307BB, PFS52, PFS75, PFS76, XL3Z9H307DB, XL3Z9H307BB, P74849H, USEP2221S, F1248A, A33265, 402-P2237S, C0067H, USEP2237S, P77404H, 4010117, 4017338 |
| Pierce | P405H |
| Precision Fuel | A30073, A30355, E16006 |
| SPECTRA PREMIUM | FG130D |
| Spectra Premium | SP2237H, SP2211H, SP2221H, SP1113 |
| TYC | 150171-A |
| TruGrade | D5341003 |
| VEMO | V99090002 |
DELPHI HP10089 Fits Vehicles
- Ford F-150 Heritage (2004)
- Ford F-250 (1997-1999)
- Ford F-150 (1997-2003)
