(888) 312-8812 Login SignupDELPHI FG0273 Fuel Pump Module Assembly
MSRP: $543.83
$29699
Save $246.84
Limited availability at this price!
In Stock
Get it by Wednesday, Feb 11
DELPHI FG0273 Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Lower amperage draws less load on vehicle's electrical system
- Part is validated, tested and matched to the right vehicle application
- Always be sure to check and clean fuel tank to avoid unnecessary returns
- Lower failure rates due to its innovative design and durability
DELPHI FG0273 Specifications
Product Attributes
| System Pressure | 62 psi |
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Seal, Instruction Sheet |
| Fuel Level Sender Assembly Included | Yes |
| Item Grade | Standard Replacement |
| Vapor Pressure Sensor | Yes |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 12 2H |
| Fuel Type | Gas |
| Regulator Included | No |
| Maximum Pressure | 109 PS |
| Terminal Type | Blade |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Lock Ring Included | No |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 2 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 40 82 |
| Resistance Ohms Full | 250 82 |
| Internal Or External Strainer | External |
| Pump Type | Electric |
| Average Current Draw | 9 68 |
| Average Flow Rating | 32 GPH |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Quantity | 1 |
| Connector Shape | Oval |
| Housing Material | Plastic |
| Installation Warnings | No |
| Connector Gender | Female |
| Fuel Filter Included | No |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 62 PS |
| Wire Harness Included | No |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | Yes |
| Universal Or Specific Fit | Specific |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Country of Origin (Primary) | TH |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604075937 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
DELPHI FG0273 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | MU1088, MU1738 |
| AUTOBEST | F2567A |
| Airtex | E3556M |
| AutoZone | DFG0273 |
| Bosch | 67317 |
| CARTER FUEL PUMPS | P75023M |
| Carquest | M2246724 |
| Carter | P75023M, P74832M |
| DENSO | 953-0035 |
| DENSO Auto Parts | 953-0035, 953-5105 |
| DORMAN | 2630376 |
| EVO Driveline | AFS0853S, RE0853S |
| GMB | 530-2120 |
| General Motors | 19180099, 25345024, 19331260, 19369909 |
| Magneti Marelli | 1AMFP00085 |
| Master Parts Division | E3556M |
| MasterPro Fuel Pumps | MPA30041 |
| N/A | 9535105, SP6610M, P76348M, USEP3556M, E3586M, F2567A, 402-P3556M, C0201M, SP6685M, 4010318 |
| Precision Fuel | A30041 |
| Spectra Premium | SP61088M |
| TYC | 150078-A |
| TruGrade | B5321024 |
| URO | GM0517254 |
DELPHI FG0273 Fits Vehicles
- Cadillac Escalade EXT (2002-2003)
- Cadillac Escalade ESV (2003)
- GMC Yukon XL 1500 (2002-2003)
- Chevrolet Suburban 1500 (2002-2003)
- Chevrolet Avalanche 1500 (2002-2003)
