(888) 312-8812 Login SignupDELPHI FG0235 Fuel Pump Module Assembly
$24699
Limited availability at this price!
In Stock
Get as soon as Friday, Sep 18
DELPHI FG0235 Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Lower amperage draws less load on vehicle's electrical system
- Part is validated, tested and matched to the right vehicle application
- Always be sure to check and clean fuel tank to avoid unnecessary returns
- Lower failure rates due to its innovative design and durability
DELPHI FG0235 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Fuel Level Sender Assembly Included | Yes |
| System Pressure | 49 psi |
| Vapor Pressure Sensor | No |
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Seal, Instruction Sheet |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 12 2H |
| Fuel Type | Gas |
| Regulator Included | Yes |
| Maximum Pressure | 73 PS |
| Terminal Type | Blade |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Lock Ring Included | No |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 1 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 224 82 |
| Resistance Ohms Full | 19 82 |
| Internal Or External Strainer | External |
| Pump Type | Electric |
| Average Current Draw | 6 68 |
| Average Flow Rating | 28 GPH |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Quantity | 1 |
| Connector Shape | Oval |
| Housing Material | Plastic |
| Installation Warnings | No |
| Connector Gender | Female |
| Fuel Filter Included | Yes |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 49 PS |
| Wire Harness Included | No |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | No |
| Universal Or Specific Fit | Specific |
Additional Information
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited |
| Warranty Special UOM | LT |
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Country of Origin (Primary) | TH |
| UPC | 00689604061725 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
DELPHI FG0235 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | MU254 |
| AUTOBEST | F3127A |
| Airtex | E7116M |
| AutoZone | DFG0235 |
| Bosch | 67656, 67711 |
| CARTER FUEL PUMPS | P74738M |
| Carquest | M2246710 |
| Carter | P74738M |
| Chrysler | 52102356, 52102193, 52012356, 4886298AA, 4897 494AA, 4897 498AA, 4897 921AA, 5012 273AA, 5012 273AB, 5012 273AC, 5012 273AD, 5012 273AE, 5012 273AF |
| DENSO | 953-3021 |
| DENSO Auto Parts | 953-3021 |
| EVO Driveline | AFS0563S, RE0563S |
| GMB | 520-2200 |
| N/A | 9533021, 4897494AA, 4897921AA, 5012273AA, 5012273AB, 5012273AC, 5012273AD, USEP7116M, F3127A, 402-P7116M, C0437M, 4010136 |
| Precision Fuel | A30064 |
| Spectra Premium | SP7116M |
| TYC | 150073-A |
| Walbro | TU137 |
DELPHI FG0235 Fits Vehicles
- Dodge Dakota (1997-2003)
