DELPHI FG0070 Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Lower amperage draws less load on vehicle's electrical system
- Part is validated, tested and matched to the right vehicle application
- Always be sure to check and clean fuel tank to avoid unnecessary returns
- Lower failure rates due to its innovative design and durability
DELPHI FG0070 Specifications
Product Attributes
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Seal, Splices, Wire Harness, Instruction Sheet |
| Item Grade | Standard Replacement |
| System Pressure | 62 psi |
| Fuel Level Sender Assembly Included | Yes |
| Vapor Pressure Sensor | Yes |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 13 2H |
| Fuel Type | Gas |
| Regulator Included | No |
| Maximum Pressure | 109 PS |
| Terminal Type | Blade |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Lock Ring Included | No |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 3 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 40 82 |
| Resistance Ohms Full | 250 82 |
| Internal Or External Strainer | External |
| Pump Type | Electric |
| Average Current Draw | 10 68 |
| Average Flow Rating | 29 GPH |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Wire Quantity | 4 |
| Grade Type | Premium |
| Connector Quantity | 1 |
| Connector Shape | Oval |
| Housing Material | Plastic |
| Installation Warnings | No |
| Connector Gender | Female |
| Fuel Filter Included | No |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 62 PS |
| Wire Harness Included | Yes |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | Yes |
| Universal Or Specific Fit | Specific |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Country of Origin (Primary) | TH |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604060070 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
DELPHI FG0070 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | MU1062, MU111, MU1751 |
| AUTOBEST | F2963A |
| Airtex | E3952M |
| AutoZone | EFG0070 |
| Bosch | 67420 |
| CARTER FUEL PUMPS | P74760M |
| Carquest | M312880 |
| Carter | P74760M, P75006M |
| DENSO Auto Parts | 953-0016 |
| DORMAN | 2630304 |
| EVO Driveline | AFS0437S, RE0437S |
| GMB | 530-2220 |
| General Motors | 19177238, 25178730, 19331267, 19369929 |
| Isuzu | 8-19177-238-0, 8-25178-730-0 |
| Magneti Marelli | 1AMFP00053 |
| MasterPro Fuel Pumps | MPA27002, MPA30027 |
| N/A | 67349, 67357, AFS0824S, RE0824S, 8191772380, 8251787300, EFP810M, E3952M, P446M, USEP3952M, F2963A, C0353M, 4010129 |
| Precision Fuel | A27002, A30027 |
| Spectra Premium | SP446M |
| TYC | 150012-A |
| TruGrade | D5331020 |
| URO | GM0517239 |
DELPHI FG0070 Fits Vehicles
- GMC Sonoma (1997-2002)
- Chevrolet S10 (1997-2002)
- Isuzu Hombre (1997-2000)
