Delphi AF10056 - Mass Air Flow Sensor
$14749
MSRP: $232.98
Save: $85.49
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DELPHI part description
Product Description
Mass Air Flow Sensor
Product Attributes
| Package Contents | Mass Air Flow Sensor - Complete Assembly, Jumper Harness, Instruction Sheet |
| Item Grade | Premium |
| Color | Black |
| Housing Included | Yes |
| Inlet Connection Diameter | 3.583 IN |
| Inlet Connection Diameter | 91 MM |
| Outlet Connection Diameter | 3.58 IN |
| Outlet Connection Diameter | 91 MM |
| Terminal Type | Blade |
| Mounting Hardware Included | No |
| Universal Or Specific Fit | Specific |
| Wire Quantity | 3 |
| Grade Type | Regular |
| Connector Quantity | 1 |
| Connector Shape | Oval |
| Housing Material | Plastic |
| Terminal Quantity | 5 |
| Connector Gender | Female |
| Terminal Gender | Male |
| Wiring Harness Included | Yes |
| Mounting Type | Band Clamp |
| Mounting Bracket Included | No |
| Sensor Casing Length | 95.5 MM |
| Sensor Casing Width | 97 MM |
| Voltage | 12.0 2H |
| Wiring Harness Length | 5.0 IN |
| Gasket Or Seal Included | No |
| Seal Quantity | 0 |
| Sensor Casing Length | 3.7 IN |
| Sensor Casing Width | 3.8 IN |
| Wiring Harness Length | 127.0 MM |
Additional Information
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9026800000 |
| Harmonized Tariff Code (HTS) | 9026802000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| UPC | 00689604197868 |
| VMRS Code | 045021019 |
| UNSPSC | 41111931 |
Part Interchanges
- 748308
- Wells SU1102
- ACDelco 213252
- ACDelco 2133457
- ACDelco 213353
- ACDelco 2134657
- 641503
- Airtex 5S2641
- Echlin MAF68308
- Richporter MA101
- Standard Motor Products MF8308
- 1618308
- Autopart International 228326
- BorgWarner 29008
- General Motors 19112572
- General Motors 19207203
- General Motors 25008308
- General Motors 25179711
- Kem 161-8308
- Spectra Premium MA101
- Carquest 64-1503
- BWD 29008
- BWD 59009
- BWD MA1061
- General Motors 19332972
- CARDONE New 86-8308
- CARDONE Reman 74-8308
- Dorman 917-824
- Standard Motor Products MAS0202
- Standard Motor Products MF8308N
- NAPA Reman Computers MAF68308
- NAPA Reman Computers XTP48308
- Blue Streak Electronics New MF8308N
- DL-6001
- 245-1067
- 245-1167
- 214129
Fits Vehicles
- Pontiac GTO (2004)
- Pontiac Firebird (1993-2002)
- GMC Yukon (1996)
- GMC Savana 3500 (1996-1997)
- GMC Savana 2500 (1996-1997)
- GMC Savana 1500 (1996-1997)
- Chevrolet Tahoe (1996)
- Chevrolet Express 3500 (1996-1997)
- Chevrolet Express 2500 (1996-1997)
- Chevrolet Express 1500 (1996-1997)
- Chevrolet Corvette (1994-2000)
- Chevrolet Camaro (1993-2002)
