DAYCO 17305 High Performance V-Belt HD with 30.5 in. Effective Length

★★★★★ (0)
17305 by DAYCO - High Performance V-Belt HD with 30.5 in. Effective Length
DAYCO
Tap to view 1 more

$18.99

Limited availability at this price!

In Stock

Get it by Monday, Jul 13
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details

DAYCO 17305 Part Description

Manufacturer

DAYCO

Product Description

V-BELT, DAYCO

DAYCO 17305 Specifications

Product Attributes

Top Width .53 in
Effective Length 30.50 in
Effective Length 774.70 mm
Outside Circumference 30.77 in
Outside Circumference 781.56 mm
Angle 36 Degrees
Material Synthetic Rubber Compound
Belt Construction Bottom Cog
Banded Belt N
Color Black
Standards SAE J636, SAE J637
Minimum Operating Temperature -37.2 C
Maximum Operating Temperature 79.4 C
Minimum Operating Temperature -35 F
Maximum Operating Temperature 175 F

Additional Information

Country of Origin (Primary) ID
Harmonized Tariff Code (Schedule B) 4010323000
UPC 00036687108364

DAYCO 17305 Cross References

BrandPart Number
DCO17305
AC DELCO17305, 2T17305, 9305HD
ALFA ROMEOB9088
ALLIS CHALMERS4834545
AutoparFB17305
BANDO3295, B3295, RPF3295
BECK ARNLEY141-0273, 141-1272
BEHR70.133.00.629
CARQUEST9305, 9305HD
CARRIER-TRANSICOLD16000143D
CONTINENTAL AG17305
CUMMINS3040280
DRIVEWORKS30517
DYNACRAFTD1102-0200, D1102-3147, D1104-9518
Duralast17305
FORDC31686, C6TA-8620-A, C6TA-8620-L, C6TZ-8620-B, C6TZ-8620-J, C6TZ-8620-R, C7TA-8620-K, C9PZ-8620-AY, D8NN-10C318-BA, ERC0400
FREIGHTLINERGT17307, GTFLN9305, GTFLN9309
GATES2/9305PB, 575TG, 8360, 8387, 9305, 9305HD
GATES (Canada)13A0775
GOODYEAR17305
GOODYEAR BELTS17305
General Motors2402309, 9433866
INTERNATIONAL/NAVISTAR434915-C91, 434916-C91, 643446-C1, 774350-C91, 780058-C91
JOHN DEEREU46257
KIAK01232611
KOMATSU600-736-9380
LAZORLITEL38-0775, L38-0785
MBL THREE STAR17305
MERCURY MARINE3736, 6490, 958481
MITSUBOSHIMF6295
MOPARB17305, B17305A
MOTORCRAFTJC-307C
NAPA25-07755, 25-07765, 25-9305, 25-9305-2, 25-9305HD
NAVISTARFLTBT17305
Navistar434915-C91, 434916-C91, 643446-C1, 774350-C91, 780058-C91
OPTIBELT12.5X775, 12.5X785
PIRELLI17-305
RENAULT77.00.673.237
ROVERERC400
THERMO KING2925B06-H18, 78-0513, 78-1026, 78-513
TOYOTA99332-10761, 99332-10765, 99332-10770, 99332-10770-78
UNIROYAL16306
VOLVO967160
WHITE02-7015076, 20804-5073, 967093, 967217, V1090789, V1090949
WISCONSINMH183

DAYCO 17305 Fits Vehicles

  • Peterbilt 362 (1992-1993)
  • International LM151 (1952)
  • Autocar C / DC (1981)
  • Western Star 4800 (1981-1988)
  • Western Star 4900 (1981-1983, 1985-1986)
  • Peterbilt 372 (1991-1993)
  • Peterbilt 377 (1991-2000)
  • Peterbilt 357 (1991-2000)
  • Peterbilt 379 (1991-2000)
  • Peterbilt 378 (1991-2000)
  • International A102 (1957-1958)
  • International S100 (1956-1957)
  • International RA122 (1953-1955)
  • International R100 (1953-1954)
  • International AM132 (1957-1958)
  • International A132 (1957-1958)
  • International AM120 (1957-1958)
  • International SM122 (1956-1957)
  • International S132 (1956-1957)
  • International SM132 (1956-1957)
  • International RM122 (1953-1955)
  • International R120 (1953-1955)
  • International LB140 (1951-1952)
  • International AM130 (1957-1958)
  • International AB120 (1957-1958)
  • International SA120 (1956-1957)
  • International SM120 (1956-1957)
  • International A130 (1957-1958)
  • International S130 (1956-1957)
  • International S120 (1956-1957)
  • International A120 (1957-1958)
  • International S112 (1956-1957)
  • International A110 (1957-1958)
  • International A122 (1957-1958)
  • International A112 (1957-1958)
  • International A100 Truck (1957-1958)
  • International SM130 (1956-1957)
  • International SA122 (1956-1957)
  • International S122 (1956-1957)
  • International S110 (1956-1957)
  • International S102 (1956-1957)
  • International RA120 (1953-1955)
  • International RA121 (1953-1955)
  • International RM121 (1953-1955)
  • International R112 (1953-1954)
  • International RM120 (1953-1955)
  • International R130 (1953-1955)
  • International R131 (1953-1955)
  • International R111 (1953-1954)
  • International R110 (1953-1954)
  • International R132 (1953-1955)
  • International LM120 (1950-1952)
  • International R122 (1953-1955)
  • International R102 (1953-1954)
  • International R121 (1953-1955)
  • International L120 (1950-1952)
  • International LM121 (1950-1952)
  • International L110 (1950-1952)
  • International L153 (1950-1952)
  • International L150 (1950-1952)
  • International L151 (1951-1952)
  • International L121 (1950-1952)
  • International L111 (1950-1952)
  • International L112 (1950-1952)
  • International LM150 (1950-1952)
  • International L122 (1950-1952)
  • International LM122 (1950-1952)
  • White WHM (1985)
  • White WHS (1983-1987)
  • White WHL (1983-1987)
  • GMC Astro (1981-1984)
  • Jaguar XKE (1970-1971)
  • Toyota Corolla (1980-1982)
  • Ford Courier (1972-1976)
  • Kia Sportage (1995-2002)
  • Alfa Romeo Spider (1983-1984)
  • Triumph TR8 (1980-1981)
  • Rover 3500 (1980)
