National Seals 710452 - National 710452 Differential Pinion Seal
- Part Number
- 710452
- Manufacturer
- NATIONAL SEALS
- Description
-
National 710452 Differential Pinion Seal
details
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
NATIONAL SEALS part description
Product Description
Differential Pinion Seal
Application Summary
1998-2000 Isuzu Amigo (Rear Outer) (Qualifier: with 8.5 (in) Ring Gear, with Spicer 44-3 Axle); 1998-1999 Isuzu Rodeo (Rear Outer) (Qualifier: with 8.5 (in) Ring Gear, with Spicer 44-3 Axle); 1998-1999 Honda Passport (Rear Outer) (Qualifier: with 8.5 (in) Ring Gear, with Spicer 44-3 Axle)
Features & Benefits
- Design type: spring loaded; multi-lip
- Temperature range: -40°F to 400°F / -40°C to 204°C
- Temperature range: -40degF to 400degF / -40degC to 204degC
- Excellent high temperature capabilities
- Compatible with wide range of fluids
- Delivers quality and reliable performance for every type of repair
Product Attributes
| Inside Diameter | 1.875 IN |
| Inside Diameter | 47.630 MM |
| Outside Diameter | 3.165 IN |
| Outside Diameter | 80.390 MM |
| Width | 0.530 in |
| Width | 13.460 MM |
| Material | Fluoro-Elastomer |
| Part Description | Oil Seal |
| Redicoat | Yes |
| Series | 710400 |
| Thickness | 0.530 IN |
| Thickness | 13.460 MM |
| Type | 72 |
| Unit of Dimension | Inch |
| Housing Bore | 3.160 IN |
| Housing Bore | 80.260 MM |
| Shaft Diameter | 1.875 IN |
| Shaft Diameter | 47.630 MM |
| Shaft Diameter | 1.875 IN |
| Grade Type | Premium |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 4016931020 |
| Harmonized Tariff Code (HTS) | 4016931020 |
| Canadian Harmonizing Tariff Code | 4016930000 |
| UPC | 00614046343757 |
Part Interchanges
Fits Vehicles
- Isuzu Rodeo (1998-1999)
- Isuzu Amigo (1998-2000)
- Honda Passport (1998-1999)
