Name: National Seals 222743 Camshaft Seal
SKU: 222743
Price: 10.49 USD
Availability: InStock

NATIONAL SEALS part description

California Proposition 65 Warning

WARNING: This product can expose you to chemical which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov. (Read more)

Product Description

Engine Camshaft Seal

Application Summary

1986-2001 Acura Integra (Liter: 1.6, 1.8, 1.7 & Engine(cc): 1590, 1834, 1678 & Cylinder: 4 & Block: L & Bore(in): 2.96, 3.19 & Bore(mm): 75.2, 81.0 & Stroke(in): 3.54, 3.50, 3.20 & Stroke(mm): 90.0, 88.8, 81.3); 1976-1983 Honda Accord (Liter: 1.6, 1.8 & Engine(cc): 1599, 1751 & Cylinder: 4 & Block: L & Bore(in): 2.95, 3.03 & Bore(mm): 75.0, 77.0 & Stroke(in): 3.54, 3.70 & Stroke(mm): 90.0, 94.0); 1973-1983 Honda Civic (Liter: 1.2, 1.3 & Engine(cc): 1169, 1237, 1335 & Engine(ci): 71 & Cylinder: 4 & Block: L & Bore(in): 2.76, 2.84 & Bore(mm): 70.0, 72.0 & Stroke(in): 2.99, 3.23 & Stroke(mm): 76.0, 82.0); 1997-2001 Honda CR-V (Liter: 2.0 & Engine(cc): 1972 & Cylinder: 4 & Block: L & Bore(in): 3.31 & Bore(mm): 84.0 & Stroke(in): 3.50 & Stroke(mm): 88.8); 1979-1991 Honda Prelude (Cylinder Head: DOHC & Liter: 1.8, 2.0 & Engine(cc): 1751, 1958 & Cylinder: 4 & Block: L & Bore(in): 3.03, 3.19 & Bore(mm): 77.0, 81.0 & Stroke(in): 3.70, 3.74 & Stroke(mm): 94.0, 95.0)

Features & Benefits

Design type: spring loaded; multi-lip
Temperature range: -80°F to 350°F / -62°C to 176°C
Good dry heat resistance
Excellent low temperature capability
Delivers quality and reliable performance for every type of repair

Product Attributes

Inside Diameter	1.063 IN
Inside Diameter	27.000 MM
Outside Diameter	1.701 IN
Outside Diameter	43.200 MM
Width	0.354 in
Width	9.000 MM
Material	Silicone
Helix Type	Counter-Clockwise-Spiral Lip Design
Part Description	Oil Seal
Series	220000
Thickness	0.354 IN
Thickness	9.000 MM
Type	32
Unit of Dimension	Metric
Housing Bore	1.693 IN
Housing Bore	43.000 MM
Shaft Diameter	1.063 IN
Shaft Diameter	27.000 MM
