MOOG 5664 Part Description
Manufacturer
Product Description
Shock Absorber
Application Summary
2013-2019 Cadillac ATS Base Luxury Premium Performance Premium Luxury (Rear) (Drive: AWD / Qualifier: Recommended OE Application -Specific Replacement)
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
Passenger Car/Light Truck Applications
| Make | Model | Year |
|---|---|---|
| CHEVROLET | BLAZER | 1997-1995 |
| S10 | 1996-1983 | |
| GMC | JIMMY | 1997-1995 |
| S15 | 1989-1983 | |
| S15 JIMMY | 1994-1992 | |
| SONOMA | 1996-1994 | |
| PONTIAC | FIREBIRD | 1992 |
MOOG 5664 Specifications
Product Attributes
| Compressed Length | 14.2 IN |
| Travel Length | 6.24 in |
| Extended Length | 20.44 in |
| Upper Mount Type | Stem Mount - Stem Length X M10 Thread Pitch |
| Gas Charged | Yes |
| Dust Shield Included | No |
| Includes Bump Stop | No |
| Upper Mount Code | S1 |
| Lower Mount Code | LS65 |
| Hydraulic Lockout | No |
| Internal Rebound Bumper | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 1" Sleeve ID X 2" Sleeve OAL |
| Part Description | Shock Absorber |
| Parts Pack(s) | P01698 |
Additional Information
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| MSDS Sheet Number | 01164 |
| UPC | 00080066118741 |
| VMRS Code | 016002002 |
| UNSPSC | 31161903 |
MOOG 5664 Cross References
| Brand | Part Number |
|---|---|
| 080066118741 | |
| ACDelco | 45H0170 |
| AutoZone | DG5851170, FCS5664S |
| Cadillac | 22942296, 22942297, 22942298, 22942589, 23172621, 23172622, 23172623, 23172624, 23469923, 23469924, 84051685, 84051686 |
| Centric Parts | 630.66096 |
| DORMAN | 566-161 |
| Duralast | FCS5664S |
| General Motors | 14047217 , 14065824 , 14047217, 14065824 |
| KYB | 3440053 |
| Mcquay-Norris | FCS5664S |
| Mevotech | SMS5664 |
| Monroe Shocks & Struts | U5664S |
| NAPA | 277-3207 |
| NAPA Chassis Parts | 277-3207 |
| NAPA Shocks | 5664 |
| Raybestos Brakes | 585-1170 |
| Sealed Power | 831-5664 |
| TRW | CS5664 |
| TRW Steering and Suspension Parts | CS5664 |
MOOG 5664 Fits Vehicles
- Pontiac Firebird (1992)
- GMC Sonoma (1994-1996)
- GMC S15 (1983-1989)
- GMC Jimmy (1992-1993, 1995-1997)
- Chevrolet S10 (1983-1989, 1994-1996)
- Chevrolet Blazer (1995-1997)
- Chevrolet Camaro (1989)
MOOG 5664 Customer Reviews
No reviews yet
Be the first to review this product!
MOOG 5664 Manufacturer Information
For over 100 years, Moog® has been an industry leader in mid- to high-end aftermarket parts for steering, suspension, and driveline systems worldwide. Utilized by daily commuters to entire fleets, Moog parts have become synonymous with reliable performance that’s just as good or even better than their OE counterparts. Moog also incorporates innovative features in their products not found in competing products, such as patented forged steel bodies and metal “gusher” bearings that greatly reduce friction across moving components. The brand also leads the way in after-sales support, with comprehensive technical assistance and training materials available for customers around the world.
MOOG 5664 Questions & Answers
No questions yet
Be the first to ask a question about this product!
