MOOG 5532 Part Description
Manufacturer
Product Description
Shock Absorber
Application Summary
2014-2019 Nissan Sentra SL SV SR S Exclusive Sense Advance (Rear) (Qualifier: Recommended OE Application -Specific Replacement)
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
The National® oil seal kit includes everything you need to get the job done.
National® has built a reputation as one of the most respected names in the industry. We have offered premium sealing solutions for more than 70 years. Our design team keeps pace with the industry and provides advanced solutions for todays vehicles.
- Low swell in hydrocarbon fluids
- Design type: spring loaded: multi-lip
- Provides good low temperature capability
- Temperature range: -40°F to 225°F: -40°C to 107°C
- Delivers quality and reliable performance for every type of repair
MOOG 5532 Specifications
Product Attributes
| Compressed Length | 18.72 IN |
| Travel Length | 1.51 in |
| Extended Length | 20.23 in |
| Gas Charged | Yes |
| Body Diameter | 1.751 IN |
| Dust Shield Included | Yes |
| Includes Bump Stop | Yes |
| Upper Mount Code | S4 |
| Lower Mount Code | LS28 |
| Hydraulic Lockout | No |
| Internal Rebound Bumper | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.5/8" Sleeve OAL |
| Part Description | Shock Absorber |
| Parts Pack(s) | P01136 |
| Upper Mount Type | Stem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch |
Additional Information
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| MSDS Sheet Number | 01164 |
| UPC | 00080066109145 |
| VMRS Code | 016002002 |
| UNSPSC | 31161903 |
MOOG 5532 Cross References
| Brand | Part Number |
|---|---|
| 080066109145 | |
| ACDelco | 45H0083 |
| AutoZone | DG5851083, FCS5532S |
| Centric Parts | 630.62051 |
| Duralast | FCS5532S |
| FCS | 346239 |
| Ford | D2LY-5310C |
| Gabriel | G511044 |
| General Motors | 1494003, 1603730, 1603729, 1603722, 1600445 |
| KYB | 3440012 |
| Mcquay-Norris | FCS5532S |
| Mevotech | SMS5532 |
| Monroe Shocks & Struts | U5532S |
| NAPA | 277-3001 |
| NAPA Chassis Parts | 277-3001 |
| NAPA Shocks | 5532 |
| Nissan | E62104AF0A, E62109AM0A |
| Perfect Circle | 277-3001 |
| Raybestos Brakes | 585-1083 |
| Sachs | 316328 |
| Sealed Power | 831-5532 |
| Sensen | 12130614 |
| TRW | CS5532 |
| TRW Steering and Suspension Parts | CS5532, JCS1506T |
MOOG 5532 Fits Vehicles
- Oldsmobile 98 (1978)
- Cadillac Fleetwood (1971-1972, 1980)
- Cadillac DeVille (1973-1976, 1980)
- Cadillac Calais (1973-1976)
MOOG 5532 Customer Reviews
No reviews yet
Be the first to review this product!
MOOG 5532 Manufacturer Information
For over 100 years, Moog® has been an industry leader in mid- to high-end aftermarket parts for steering, suspension, and driveline systems worldwide. Utilized by daily commuters to entire fleets, Moog parts have become synonymous with reliable performance that’s just as good or even better than their OE counterparts. Moog also incorporates innovative features in their products not found in competing products, such as patented forged steel bodies and metal “gusher” bearings that greatly reduce friction across moving components. The brand also leads the way in after-sales support, with comprehensive technical assistance and training materials available for customers around the world.
