MOOG 5400 Part Description
Manufacturer
Product Description
Coil Spring Set
Application Summary
1968-1972 Buick Sportwagon (Front) (Liter: 5.7, 6.6 / Qualifier: Constant Rate Spring); 1968 Chevrolet Chevelle SS (Front) (Liter: 6.5 / Qualifier: Constant Rate Spring); 1968-1970 Chevrolet El Camino (Front) (Liter: 5.3, 6.5, 6.6 & Transmission Base Type: Transmission & Transmission Control Type: Automatic, Manual / Qualifier: Standard Duty, Constant Rate Spring, Heavy Duty); 1970 Pontiac Tempest (Front) (Doors: 2 & Body: Convertible & Liter: 5.7 / Qualifier: Heavy Duty, Constant Rate Spring)
Features & Benefits
- 100% Load tested
- Easy to install
- Provides like-new steering
- Designed to lower stresses for longer service life
- Worn or sagging coil springs can cause premature tire wear due to vehicle misalignment
Moog Front Coil Springs OE comparable -MOOG COIL SPRINGS, SOLD AS PAIR -- Constant Rate Springs, High Quality Direct Fit OEM Replacement Coil Springs, Made From Heat-Treated Alloy Steel For A Full Coil Rebound And Sagging Resistance, Return Ride Height And Body Sway To Original Performance Levels, Restore Vehicle Handling, Use A Premium Urethane Tube That Lasts Much LongerFront
MOOG 5400 Specifications
Product Attributes
| Wire Diameter | 0.65 IN |
| Wire Diameter | 16.70 MM |
| Spring Color | Black |
| Front Spring Outside Diameter | 4.930 IN |
| Front Spring Relaxed Length | 17.06 IN |
| Front Spring Relaxed Length | 433.30 MM |
| Front Spring Compressed Length | 11.00 IN |
| Front Spring Compressed Length | 279.40 MM |
| Rear Spring Relaxed Length | 17.06 IN |
| Rear Spring Relaxed Length | 433.30 MM |
| Rear Spring Compressed Length | 11.00 IN |
| Rear Spring Compressed Length | 279.40 MM |
| Rear Spring Outside Diameter | 4.930 IN |
| Part Description | Coil Spring Set |
Additional Information
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 7320200020 |
| Harmonized Tariff Code (Schedule B) | 7320201000 |
| Harmonized Tariff Code (HTS) | 7320201000 |
| Refurbished Part | N |
| Remanufactured Part | N |
| UPC | 00080066126425 |
| VMRS Code | 016002002 |
| UNSPSC | 31161903 |
MOOG 5400 Cross References
| Brand | Part Number |
|---|---|
| 080066126425 | |
| ACDelco | 45H0047 |
| AutoZone | FCS5400S |
| Centric Parts | 630.66006 |
| DORMAN | 614-003, 614-004, 566-181 |
| Duralast | FCS5400S |
| General Motors | 400884, 400981, 401174, 3923384, 3926994, 404856, 400987, 3952821, 3931471, 400985, 26001363, 26001365, 26011291, 26018968, 26018970, 26020732, 26032807, 26036985, 26037370 |
| Maremont | 94-2828 |
| Mcquay-Norris | FCS5400S |
| Mevotech | SMS5400 |
| Mevotech Supreme | SMS5400 |
| Monroe Shocks & Struts | U5400S |
| NAPA | 277-1952 |
| NAPA Chassis Parts | 277-1952 |
| Perfect Circle | 277-1952, 277-1955, 6-1518X, 6-2828X, 66-1518, 66-2828 |
| Pontotoc | U5400S |
| Raybestos Brakes | 585-1047, 816-8067, 8162828 |
| Roadmates | 110502 |
| Sealed Power | 831-5400 |
| TRW | CS5400 |
| TRW Steering and Suspension Parts | 224120, 224152, CS5400, JCS1494T |
MOOG 5400 Fits Vehicles
- Pontiac Tempest (1970)
- Buick Sportwagon (1968-1969, 1971-1972)
- Chevrolet El Camino (1968, 1970)
- Chevrolet Chevelle (1968)
MOOG 5400 Customer Reviews
No reviews yet
Be the first to review this product!
MOOG 5400 Manufacturer Information
For over 100 years, Moog® has been an industry leader in mid- to high-end aftermarket parts for steering, suspension, and driveline systems worldwide. Utilized by daily commuters to entire fleets, Moog parts have become synonymous with reliable performance that’s just as good or even better than their OE counterparts. Moog also incorporates innovative features in their products not found in competing products, such as patented forged steel bodies and metal “gusher” bearings that greatly reduce friction across moving components. The brand also leads the way in after-sales support, with comprehensive technical assistance and training materials available for customers around the world.
