(888) 312-8812 Login SignupSEALED POWER CS-1558 Engine Camshaft
$574.34
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
SEALED POWER CS-1558 Part Description
Manufacturer
Product Description
Engine Camshaft
Application Summary
1993-1992 DT L/D V8 318CI 5.2L; 2002-1993 DT L/D V8 360CI 5.9L; 1994-1993 JEE L/D V8 318CI 5.2L
Features & Benefits
- Meets or exceeds OEM specs
- Original equipment performance
- Idle: Stock
- Latest high quality materials
- Precision machining
- Made in USA
SEALED POWER CS-1558 Specifications
Product Attributes
| Exhaust Valve Lift | 0.2650 IN |
| Exhaust Valve Lift | 6.731 MM |
| Intake Valve Lift | 0.2650 IN |
| Intake Valve Lift | 6.731 MM |
| Exhaust Duration at .050 inch Lift | 259 |
| Intake Duration at .050 Inch Lift | 270 |
| Lobe Separation | 114 |
| Cam Type | Hydraulic Roller |
| Design Feature | Roller Cam |
| Exhaust Duration | 259 |
| Exhaust Lift | 0.2650 in (6.731 mm) |
| Exhaust Lobe Center | 116 |
| Footnote Code | (050) Duration at .050 Lobe Lift |
| Intake Duration | 270 |
| Intake Lift | 0.2650 in (6.731 mm) |
| Intake Lobe Center | 112 |
| Lobe Separation | 114 |
| Overlap | 33 |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8483101030 |
| Harmonized Tariff Code (HTS) | 8483101030 |
| Remanufactured Part | N |
| UPC | 00614046225527 |
