Gates 23570 - Premium Modular Coolant Hose
$10499
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
GATES part description
Product Description
Premium Modular Coolant Hose
Application Summary
2009-07 Mazda, 3, 4-Cyl. 2.0 L, Lower - Rad. To Thermostat
Features & Benefits
- Specifically-engineered materials resist collapse under vacuum
- Specifically-engineered materials resist collapse under vacuum
- Engineered to resist electrochemical degradation - the leading cause of hose failure
- Engineered to resist electrochemical degradation – the leading cause of hose failure
- EPDM tube; synthetic fiber knit reinforcement, heat-, ozone- and chemical coolant-resistant EPDM cover
- Manufactured with OEM-exact hose components (quick connects, branch connectors/tees, sensors, etc.)
- Meets SAE 20R3 EC Class D1 under 25mm (1 in.) ID, SAE 20R4 EC Class D1 for 25mm (1 in.) ID and over
- Temperature Range: -40 Deg. F to +257 Deg. F (-40 Deg. C to +125 Deg. C)
- Note: Gates recommends replacing clamps each time a new coolant hose is installed
- Caution: Do not use for fuel or oil transfer applications
Product Attributes
| Centerline Length | 17.9 IN |
| Modular | Yes |
| Modular Components Included | Branch |
| Branch Quantity | 1 |
| Quick Connect Fitting Quantity | 0 |
| End 1 Inside Diameter | 1.25 in |
| End 2 Inside Diameter | 1.25 in |
| End 3 Inside Diameter | .82 in |
| Contains Spring | No |
| Material | EPDM, Plastic |
| Molded | Yes |
| Centerline Length | 21 MM |
| End 1 Inside Diameter | 32 MM |
| End 2 Inside Diameter | 32 MM |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 4009310000 |
| UPC | 00770075420668 |
| VMRS Code | 042004014 |
| UNSPSC | 40142000 |
Part Interchanges
Fits Vehicles
- Mazda 3 Sport (2009)
- Mazda 3 (2004-2009)
