(888) 312-8812 Login SignupMERITOR M83147 Suspension Shock Absorber, Standard, 2.00 in. Body Diameter, 1.26 in. Shock Absorber Bore Size
Tap to view 1 more
MSRP: $148.32
$5649
Save $91.83
Limited availability at this price!
In Stock
Get as soon as Tuesday, Sep 15
MERITOR M83147 Part Description
Manufacturer
Product Description
Shock Absorber
Meritor Suspension Shock Absorber
Over highway seams, yard ruts, and uneven dock approaches, the Meritor Suspension Shock Absorber helps settle chassis movement after the suspension takes a hit. Springs carry the load, but the shock controls the motion that follows. This CL14 shock supports suspension service when ride control, tire contact, and driver comfort need a stronger damping point in the system. The Meritor M83147 helps commercial vehicles feel more composed through daily routes without changing the suspension layout.
| Body Diameter (in.) | 2.00 in. |
| Body Diameter (mm) | 50.8 mm |
| Bore (in.) | 1.38 in. |
| Bore (mm) | 35 mm |
| Collapsed Length (in.) | 17.36 in. |
| Collapsed Length (mm) | 440.9 mm |
| Dust Shield Diameter (in.) | 2.38 in. |
| Dust Shield Diameter (mm) | 60.5 mm |
| Extended Length (in.) | 28.53 in. |
| Extended Length (mm) | 724.6 mm |
| Family Code | 35FCWC |
| Hydraulic Stop | Yes |
| Stroke | 283.7 mm |
| Stroke Inch | 11.17 in. |
| Type | Standard |
| VMRS Code | 016-008-003 |
Meritor Shock Absorber
Meritor shock absorber is designed for exceptional day-in and day-out performance for trucks, trailers, and other types of heavy duty commercial vehicles. This shock provides better ride comfort, operational control, and cargo protection than what the competition has to offer.
Features & Benefits
- Hydraulic Extension Stop technology provides cushioning at full extension for optimum force absorption
- Advanced gas cell system reduces oil cavitation from heavy use, maximizing damping efficiency and extending shock life
- Hardened piston rod with polished chrome coating for superior corrosion resistance
- Made of premium materials to ensure reliable performance even under extreme conditions
- Parts covered by a 1-year limited warranty against defects
- Reduces bounce after repeated road inputs and chassis movement
- Driver comfort improves as harsh movement settles more quickly
MERITOR M83147 Specifications
Product Attributes
| Body Diameter (in.) | 2.00 in. |
| Body Diameter (mm) | 50.8 mm |
| Bore (in.) | 1.26 in. |
| Bore (MM) | 32 mm |
| Brand | Meritor |
| Collapsed Length (in.) | 17.36 in. |
| Collapsed Length (mm) | 441 mm |
| Dust Shield Diameter (in.) | 2.36 in. |
| Dust Shield Diameter (mm) | 60 mm |
| Extended Length (in.) | 28.54 in. |
| Extended Length (mm) | 725 mm |
| Family Code | 35FCWC |
| Hydraulic Stop | Yes |
| Pallet Quantity | 198 |
| Stroke | 284 mm |
| Stroke Inch | 11.18 in. |
| Type | Standard |
| Weight | 7.00 |
| Body Diameter | 2.00 in. |
| Compressed Length | 17.36 in. |
| Dust Shield Diameter | 2.36 in. |
| Extended Length | 28.54 in. |
| Shock Absorber Bore Size | 1.26 in. |
| Shock Stroke | 284 mm |
| Type | Standard |
MERITOR M83147 Cross References
| Brand | Part Number |
|---|---|
| TDAM83147, 14QK424M, 1516307850, 315611, 606706, 606755, HD60670006, MERM83147 | |
| Automann | A83147 |
| DAYTON PARTS BATCO | 341606706, M65505 |
| GABRIEL | 83147 |
| HENDRICKSON | 60670-006, 60670006, 60670006L |
| HENDRICKSON TRUCK SUSPENSION SYSTEMS | 60670-006, 98583-016, 659155, 654896 |
| MACK | 20570098, 14QK-424M, 60670-006 |
| MONROE | 65505, 66463 |
| Monroe Shocks & Struts | 65505 |
