Haldex 40010143 - Automatic Brake Adjuster (ABA) - Rear Brake, 5.5 in. Arm Length, 1.5 in. (Spline Diameter), 10 (Spline Quantity)
$14249
MSRP: $253.30
Save: $110.81
In stock
limited availability at this price!
Pay over 3-12 months with . Learn more
HALDEX part description
Product Description
Auto Brake Adjusters, Drive Axle & Std App. Arm Length 5-1/2" Offset 0
Application Summary
Drive Axle Applications, Standard Applications. 6.5" version use P/N 40050004. , Compatible with all major brand clevises
Features & Benefits
- Covers more applications than competing adjusters in the market
- Compatible with clevises from major OE and aftermarket brands
- Easily accessible hex nut for easy adjustment and maintenance
- Specially-crafted wormshaft provides added resistance against fatigue
- Heavy duty gaskets and O-rings seal out moisture and contaminants
- Fully-sealed design protects linkages against the elements for added durability
- Helps prevent uneven tire and brake wear for added savings on maintenance and operating expenses
- Heat-treated steel alloy internal gears provide increased strength and wear resistance
Haldex Automatic Brake Adjuster (ABA) Service Kit
Improve your ride’s stopping performance with the Haldex automatic brake adjuster (ABA) service kit. This kit already includes the air brake automatic slack adjuster and other components you need to service your truck’s air braking system.
Product Attributes
Anchor Bracket Style | Strap |
Arm Hole Diameter | 5/8 in. |
Arm Length | 5-1/2 in. |
Body Angle | 34 DD |
Freight Class | 70 |
Grease Fitting Location | 180 DD |
Grease Fitting Type | Straight |
Location | Rear |
Offset | 0 in. |
Pin Diameter | 5/8 in. |
Recommended Bracket Number | 42710553 |
Spline Diameter | 1-1/2 in. |
Spline Quantity | 10 |
Additional Information
Country of Origin (Primary) | US |
Harmonized Tariff Code (Schedule B) | 8708305090 |
Harmonized Tariff Code (HTS) | 8708305090 |
Remanufactured Part | N |
Warranty Distance | 100000 |
Warranty Distance UOM | MI |
Warranty Special | 72 MO, 1 MIL MI=Haldex ABA/SABA (409 Part Number Prefix)(1), 36 MO, Unlimited MI=Haldex ABA (NL/429 Part Number Prefix)(1). 24 MO, 200K MI=Haldex ABA(8). 24 MO, 100K MI=Haldex ABA/S-ABA(3) & Non-Haldex ABA. 12 MO, 100K MI=Haldex ABA(9). See L20221W.pdf |
Warranty Time | 12 |
Warranty Time UOM | MO |
UPC | 00767653143392 |
VMRS Code | 013002035 |
Part Interchanges
- E-10780A
- SA07804
- 400-10103
- L3607
- 04-06-6020
- 40010143
- A11-3275-1045
- 317166
- 10-400-10143
- 253589
- FLT40010143
- 20523327
- 1538610
- 4W8045
- 1656903C91
- 03-04545
- A-3-3275-F-1045
- 61130149
- 76401-3431
- 25QD260M6
- 03-05886
- 61045
- M-3932ASS
- U55 40010143
- SA10103
- WA10143
- 41420623
- RB-10143
- OTR10143
- Euclid E-10780A
- Gunite SA07804
- Haldex 400-10103
- Leland L3607
- MCI 04-06-6020
- Midland 40010143
- Meritor A11-3275-1045
- Eaton 317166
- Dana Commercial Vehicle Service Parts 10-400-10143
- Emergency One 253589
- Fleetrite FLT40010143
- Volvo 20523327
- Oshkosh 1538610
- Mei 4W8045
- Navistar 1656903C91
- Paccar Parts 03-04545
- Rockwell International A-3-3275-F-1045
- Thomas Built Buses 61130149
- Western Star 76401-3431
- Mack 25QD260M6
- Kenworth 03-05886
- Peterbilt 03-05886
- Di-Pro Inc. 61045
- Neoplan M-3932ASS
- Ryder U55 40010143
- Sirco Industries SA10103
- World American WA10143
- Wabash National 41420623
- RANGER BRAKE RB-10143
- OTR OTR10143
- EUCLID E-10780A
- Euclid E-6915
- Euclid E-6924
- Euclid E-6924-B
- Euclid E-6924A
- Euclid E-6924B
- GUNITE SA07804
- Gunite SA08604
- Gunite SA09904
- Gunite SAS1025
- Gunite SAS1034
- Gunite SAS1134
- Haldex 400-10143
- Haldex 409-10134
- Haldex 409-10135
- Haldex 409-10223
- Haldex 409-10238
- Haldex 409-10313
- Haldex 409-10387
- Haldex 409-10412
- Haldex 409-10509
- Haldex 409-10548
- Haldex 409-10555
- Haldex 409-10565
- Haldex 409-10649
- Haldex 409-10733
- Haldex 409-10797
- Haldex 409-10813
- Haldex 409-10860
- Haldex 40910643
- Haldex 40910649
- Haldex 429-10627
- Haldex 429-10649
- Haldex 4NL10157
- Haldex 500-10143
- Haldex 509-10134
- Haldex 509-10135
- Haldex 509-10238
- Haldex 509-10387
- Haldex 509-10412
- Haldex 509-10548
- Haldex 509-10565
- Haldex 509-10627
- Haldex 509-10649
- Haldex 509-10733
- Haldex 509-10860
- Haldex 609-10134
- Haldex 609-10135
- Haldex 609-10238
- Haldex 609-10313
- Haldex 609-10387
- Haldex 609-10412
- Haldex 609-10509
- Haldex 609-10548
- Haldex 609-10555
- Haldex 609-10565
- Haldex 609-10627
- Haldex 609-10649
- Haldex 609-10733
- LELAND L3607
- MIDLAND 40010143
- Midland 409-10733
- Midland 429-10627
- MERITOR A11-3275-1045
- Meritor A11-3275-F-1046
- Meritor A16-3275-H-1152S
- Meritor A3-3275-E-1045
- Meritor A3-3275-F-1046
- Meritor A4-3275-W-1193
- Meritor A4-3275-X-1194
- Meritor A5-3275-E-1045
- Meritor A5-3275-F-1046
- Meritor A6-3275-E-1045
- Meritor A6-3275-F-1046
- Meritor R801041
- Meritor R801048
- Meritor R802361
- Meritor R802362
- Meritor R802363
- Meritor R802370
- Meritor R802371
- Meritor R802644
- Meritor R806022
- Eaton 506726
- Eaton 507032
- Eaton 807566
- Eaton 808125
- Eaton 808139
- Eaton 808162
- Eaton 808176
- Eaton 808688
- Eaton 809613
- Eaton 810180
- Eaton 810728
- Eaton 811847
- Eaton 815790
- Eaton 815809
- Eaton 818220
- Eaton 818301
- Eaton 818552
- Eaton 819036
- Eaton 825468
- Eaton 973530
- Eaton 974042
- Eaton 974167
- Eaton 975628
- Eaton 975876
- DANA/SPICER BRAKE 10-400-10143
- Dana Commercial Vehicle Service Parts M12WR125
- EMERGENCY ONE 253589
- FLEETRITE FLT40010143
- VOLVO 20523327
- Volvo 20714908
- Volvo 2516-5179
- Volvo 3946255
- Oshkosh 2170130
- Oshkosh 61130149
- Oshkosh M-3932ASS
- NAVISTAR 1656903C91
- Navistar 1656904C91
- Navistar 1656905C91
- Navistar 1656906C91
- Navistar 1656907C91
- Navistar 1656908C91
- Navistar 1658848C91
- Navistar 1694310C91
- Navistar 1694312C91
- Navistar 1694313C91
- Navistar 1694318C91
- Navistar 1694319C91
- Paccar Parts 03-05886
- Paccar Parts 03-07649
- ROCKWELL A-3-3275-F-1045
- Rockwell International A11-3275-E-1045
- Rockwell International A11-3275-F-1046
- Rockwell International A3-3275-D-1148
- Rockwell International A3-3275-E-1045
- Rockwell International A3-3275-E-1149
- Rockwell International A4-3275-W-1193
- Rockwell International A4-3275-X-1194
- Rockwell International A43-3275-A-599
- Rockwell International A5-3275-E-1045
- Rockwell International A5-3275-F-1046
- Rockwell International A6-3275-E-1045
- Rockwell International A6-3275-F-1046
- Western Star 76401-3436
- Western Star 76401-3484
- Western Star 76401-3521
- Mack 25QD410P4
- Mack 25QD410P7
- PETERBILT 03-05886
- Peterbilt 03-07645
- DI-PRO 61045
- RYDER FLEET PROD. U55 40010143
- WORLD AMERICAN WA10143
- EUCLID E-6915
- EUCLID E-6924
- EUCLID E-6924-B
- EUCLID E-6924A
- EUCLID E-6924B
- GUNITE SA08604
- GUNITE SA09904
- GUNITE SAS1025
- GUNITE SAS1034
- GUNITE SAS1134
- MIDLAND 409-10733
- MIDLAND 429-10627
- MERITOR A11-3275-F-1046
- MERITOR A16-3275-H-1152S
- MERITOR A3-3275-E-1045
- MERITOR A3-3275-F-1046
- MERITOR A4-3275-W-1193
- MERITOR A4-3275-X-1194
- MERITOR A5-3275-E-1045
- MERITOR A5-3275-F-1046
- MERITOR A6-3275-E-1045
- MERITOR A6-3275-F-1046
- MERITOR R801041
- MERITOR R801048
- MERITOR R802361
- MERITOR R802362
- MERITOR R802363
- MERITOR R802370
- MERITOR R802371
- MERITOR R802644
- MERITOR R806022
- DANA/SPICER BRAKE M12WR125
- VOLVO 20714908
- VOLVO 2516-5179
- VOLVO 3946255
- NAVISTAR 1656904C91
- NAVISTAR 1656905C91
- NAVISTAR 1656906C91
- NAVISTAR 1656907C91
- NAVISTAR 1656908C91
- NAVISTAR 1658848C91
- NAVISTAR 1694310C91
- NAVISTAR 1694312C91
- NAVISTAR 1694313C91
- NAVISTAR 1694318C91
- NAVISTAR 1694319C91
- ROCKWELL A11-3275-E-1045
- ROCKWELL A11-3275-F-1046
- ROCKWELL A3-3275-D-1148
- ROCKWELL A3-3275-E-1045
- ROCKWELL A3-3275-E-1149
- ROCKWELL A4-3275-W-1193
- ROCKWELL A4-3275-X-1194
- ROCKWELL A43-3275-A-599
- ROCKWELL A5-3275-E-1045
- ROCKWELL A5-3275-F-1046
- ROCKWELL A6-3275-E-1045
- ROCKWELL A6-3275-F-1046
- PETERBILT 03-07645
- MACK 25QD260M6
- MACK 25QD410P4
- MACK 25QD410P7
- WESTERN STAR 76401-3431
- WESTERN STAR 76401-3436
- WESTERN STAR 76401-3484
- WESTERN STAR 76401-3521
HALDEX 40010143 Cross Reference
We have 28 alternatives for the 40010143 by HALDEX:
- OTR10143
- E-6962
- 013-002-028
- 40010143
- HDX400-10143
- HDX40010143
- HD VALUE HDV-10143
- BWP-NSI R-10143
- RANGER 10143
- NAVISTAR FLT40010143
- HALDEX 40010143M1D
- MERITOR R806022A
- MERITOR M807022
- STEMCO MK41100S
- AUTOMANN 133.1031
- BWP M-4058
- DAYTON 05-661
- EUCLID E-6924B
- HALDEX 40010121
- HALDEX 40010143
- HALDEX 40910733
- HALDEX 40910813
- HALDEX 400-10143
- HALDEX 409-10733
- HALDEX 409-10813
- LELAND L3607
- MERITOR R806022
- SPICER 818552
