GATES TR30698 Part Description
Manufacturer
Product Description
Green Stripe Truck & Bus Series V-Belt
Application Summary
Caterpillar, 627B (14S), Caterpillar 3306T Diesel, Fan & Alt.
Features & Benefits
- Molded notches reduce bending stress, especially on small diameter pulleys, while dissipating heat
- High modulus, high strength tensile cord
- Oil and heat-resistant construction throughout
- Meets SAE J636b and SAE J637 specifications
- Meets RMA oil and heat resistant standards and static conductivity requirements
- NOTE: Some sizes available as Gates PowerBand joined V-belts
GATES TR30698 Specifications
Product Attributes
| Type | Truck & Bus V-Belt |
| Cross Section Designation | W |
| Angle | 36 |
| Strand Quantity | 1 |
| Top Width | .875 in |
| Outside Circumference | 70.38 in |
| Effective Length | 69.8 in |
| Construction | Notched |
| Notched | Yes |
| Belt Material | EPDM |
| Cord Material | Polyester |
| Top Width | 22 mm |
| Outside Circumference | 1788 mm |
| Effective Length | 1773 mm |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4010323000 |
| Country of Origin (Primary) | US |
| Stock Status | N |
| UPC | 00072053275131 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
GATES TR30698 Cross References
| Brand | Part Number |
|---|---|
| 86200310 | |
| ACDelco | T30698 |
| Carquest | TR30698 |
| Caterpillar | 1C6608, 2W4548, 35H4207, 5M4207 |
| Dayco | 30700 |
| GOODYEAR BELTS | 30698 |
| Komatsu | 0412022570 |
| Metric | 22A1775 |
