Gates TR30428 - Green Stripe Truck & Bus Series V-Belt
$2199
5 day lead time
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
GATES part description
Product Description
Green Stripe Truck & Bus Series V-Belt
Application Summary
Baker, FG60, Hercules QXD3, Fan & Gen.
Features & Benefits
- Molded notches reduce bending stress, especially on small diameter pulleys, while dissipating heat
- High modulus, high strength tensile cord
- Oil and heat-resistant construction throughout
- Meets SAE J636b and SAE J637 specifications
- Meets RMA oil and heat resistant standards and static conductivity requirements
- NOTE: Some sizes available as Gates PowerBand joined V-belts
Product Attributes
| Type | Truck & Bus V-Belt |
| Cross Section Designation | W |
| Angle | 36 |
| Strand Quantity | 1 |
| Top Width | .875 in |
| Outside Circumference | 43.48 in |
| Effective Length | 42.9 in |
| Construction | Notched |
| 9837 | Yes |
| Belt Material | EPDM |
| Cord Material | Polyester |
| Top Width | 22 mm |
| Outside Circumference | 1104 mm |
| Effective Length | 1090 mm |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 4010323000 |
| UPC | 00072053275445 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
Part Interchanges
- Mopar BH-264
- Mopar BH-89
- Mopar BH-94
- White 141103
- White 141106
- White 438928
- White 62691
- White CO5578
- White 204126A
- ACDelco T30428
- Dayco 904M
- BF Goodrich 30432
- Carquest TR30428
- Allis Chalmers 4613868
- Allis Chalmers ASE498
- Bendix-Westinghouse 237425
- British Leyland 1B1280
- Caterpillar 617148
- Chrysler C102608
- Divco Trucks 4359
- Dresser 20011
- Dresser 51277
- Galion RD37724
- Gardner Denver 13C68
- General Motors 2194218
- General Motors 839368
- Hyster 12553
- Huber B762
- Koehring 12192
- Lincoln Electric S8640
- Waukesha 116397
- Waukesha 61203
- Waukesha A61203
- Mack 88GB330P33
- Mack 88GB330P9
- Brockway 207812
- Goodyear 32434
- NAPA Belts/Hose 25-30428
- Durkee-Atwood 28-423
- Grumman Flxible 17R07
- Grumman Flxible 25BR41
- MBL Three Stars 30430
- NAPA 25-10880
- Otis 14Y9031
- Service King 130BP
- Yale 564251
- Yale 6070G4016
- <Unknown> 104448H
- <Unknown> 11894
- <Unknown> 1C10674
- <Unknown> 32440
- <Unknown> 58166H
- Metric 22A1090
- Goodyear 28429
Fits Vehicles
- Ford Super Deluxe (1948)
- GMC 370 (1956-1959)
- GMC S370 (1956-1958)
- GMC F350 (1956-1959)
- GMC F370 (1956-1959)
- Ford Deluxe (1948)
